BLOWER DATA - BELT DRIVE - 3 TON
BLOWER TABLE INCLUDES RESISTANCE FOR BASE UNIT ONLY WITH DRY INDOOR COIL AND AIR FILTERS IN PLACE.
FOR ALL UNITS ADD:
1 - Any factory installed options air resistance (heat section, economizer, etc.).
2 - Any eld installed accessories air resistance (duct resistance, diffuser, etc.).
See Page 20 for blower motors and drives and wet coil and options/accessory air resistance data.
DOWNFLOW
Air
Volume
(cfm)
External Static (in.w.g.)
0.10 0.20 0.30 0.40 0.50 0.60 0.70 0.80 0.9 1.0
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
700 447 0.09 517 0.12 589 0.15 663 0.17 739 0.19 815 0.2 883 0.23 938 0.25 988 0.27 1039 0.29
800 465 0.1 534 0.14 605 0.17 678 0.19 753 0.21 825 0.23 890 0.25 946 0.27 996 0.3 1047 0.32
900 486 0.12 554 0.16 623 0.2 695 0.22 767 0.23 836 0.25 897 0.28 953 0.3 1004 0.33 1055 0.35
1000 508 0.15 576 0.19 643 0.22 713 0.24 783 0.26 848 0.28 907 0.3 961 0.33 1011 0.36 1062 0.38
1100 533
0.18 599 0.22 665 0.25 733 0.27 800 0.28 863 0.31 919 0.34 971 0.36 1020 0.39 1070 0.41
1200 560 0.21 625 0.25 689 0.28 755 0.3 820 0.32 879 0.34 932 0.37 983 0.4 1031 0.43 1079 0.45
1300 591 0.24 654 0.28 716 0.31 779 0.33 841 0.35 897 0.38 948 0.41 996 0.44 1044 0.47 1091 0.49
1400 631 0.26 690 0.3 748 0.34 807 0.36 864 0.39 916 0.42 964 0.46 1011 0.49 1058 0.51 1105 0.54
Air
Volume
(cfm)
External Static (in.w.g.)
1.1 1.2 1.3 1.4 1.5 1.6 1.7 1.8 1.9 2.0
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
700 1088 0.31 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
- - - - - - - - - - - - - - -
800 1098 0.34 1144 0.36 1185 0.39 1224 0.42 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
900 1106 0.37 1152 0.4 1193 0.43 1232 0.46 1269 0.49 1305 0.52 1340 0.55 1376 0.59 - - - - - - - - - - - -
1000 1111 0.41 1157 0.43 1199 0.47 1238 0.5 1276 0.53 1311 0.56 1347 0.6 1382 0.63 1417 0.67 1452 0.7
1100 1118 0.44 1163 0.47 1206 0.51 1245 0.54 1282 0.58 1318 0.61 1353 0.65 1388 0.68 1423 0.72 1458 0.75
1200 1127 0.48 1171 0.52 1213 0.55 1252 0.59 1289 0.62 1324 0.66 1358 0.7 1393 0.73 1428 0.77 1463 0.81
1300 1137 0.53 1181 0.56 1221 0.6 1259 0.64 1296 0.68 1330 0.71 1364 0.75 1398 0.78 1432 0.82 1467 0.86
1400 1150 0.57
1191 0.61 1231 0.65 1268 0.69 1303 0.73 1337 0.77 1371 0.8 1404 0.84 1437 0.88 1473 0.91
