BLOWER DATA - BELT DRIVE - 3 TON
BLOWER TABLE INCLUDES RESISTANCE FOR BASE UNIT ONLY WITH DRY INDOOR COIL AND AIR FILTERS IN PLACE.
FOR ALL UNITS ADD:
1 - Any factory installed options air resistance (heat section, economizer, etc.).
2 - Any eld installed accessories air resistance (duct resistance, diffuser, etc.).
See Page 20 for blower motors and drives and wet coil and options/accessory air resistance data.
HORIZONTAL
Air
Volume
(cfm)
External Static (in.w.g.)
0.10 0.20 0.30 0.40 0.50 0.60 0.70 0.80 0.9 1.0
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
700 445 0.08 516 0.11 591 0.13 670 0.15 753 0.16 820 0.19 870 0.22 918 0.24 969 0.27 1021 0.29
800 463 0.09 534 0.12 608 0.14 685 0.16 766 0.18 830 0.21 878 0.24 926 0.27 977 0.29 1030 0.32
900 485 0.11 554 0.14 627 0.16 703 0.18 780 0.21 841 0.23 888 0.27 935 0.3 986 0.32 1039 0.35
1000 509 0.13 578 0.16 649 0.19 722 0.21 796 0.23 854 0.26 900 0.29 947 0.33 997 0.35 1048 0.38
1100 537
0.16 605 0.19 674 0.21 744 0.24 813 0.26 868 0.29 913 0.33 959 0.36 1008 0.39 1059 0.41
1200 567 0.19 633 0.22 700 0.24 768 0.27 833 0.3 884 0.33 928 0.37 974 0.4 1022 0.43 1071 0.45
1300 599 0.22 664 0.25 729 0.28 793 0.3 853 0.33 902 0.37 945 0.41 990 0.44 1037 0.47 1085 0.5
1400 634 0.26 697 0.29 758 0.31 819 0.34 875 0.38 921 0.42 964 0.46 1008 0.49 1054 0.52 1100 0.54
Air
Volume
(cfm)
External Static (in.w.g.)
1.1 1.2 1.3 1.4 1.5 1.6 1.7 1.8 1.9 2.0
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
700 1071 0.32 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
- - - - - - - - - - - - - - -
800 1082 0.34 1128 0.37 1169 0.4 1205 0.42 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
900 1090 0.37 1137 0.4 1177 0.43 1214 0.46 1248 0.49 1280 0.51 1310 0.54 1340 0.57 - - - - - - - - - - - -
1000 1098 0.41 1143 0.44 1184 0.47 1221 0.5 1255 0.53 1287 0.56 1318 0.59 1347 0.61 1377 0.64 1406 0.67
1100 1107 0.44 1150 0.47 1191 0.51 1228 0.54 1263 0.57 1295 0.6 1325 0.63 1355 0.66 1384 0.69 1413 0.72
1200 1117 0.48 1160 0.52 1200 0.55 1237 0.59 1271 0.62 1303 0.66 1334 0.69 1363 0.72 1392 0.75 1420 0.78
1300 1130 0.53 1171 0.57 1210 0.6 1246 0.64 1280 0.68 1312 0.71 1342 0.74 1372 0.78 1400 0.81 1429 0.84
1400 1144 0.58
1183 0.62 1221 0.66 1256 0.7 1290 0.73 1321 0.77 1352 0.8 1381 0.84 1410 0.87 1439 0.9
