E1EH 7.5, 15, 22.5, 30 -Y ELECTRIC HEAT
Lennox Commercial
HEATING
DESCRIPTION
KEY
DESCRIPTION
A55
PANEL, MAIN
F3
FUSE, ELECTRIC HEAT
F4
FUSE, UNIT
HE −1
ELEMENT, ELECTRIC HEAT 1
HE −2
ELEMENT, ELECTRIC HEAT 2
HE −3
ELEMENT, ELECTRIC HEAT 3
J2
JACK, ELECTRIC HEAT
J265C
JACK, CONTACTOR RELAY
J266A
JACK, HEATING CONTROL STG 1
J271A,B JACK, HEATING SENSORS STG 1
K15,−1 CONTACTOR, ELECTRIC HEAT 1
P2
PLUG, ELECTRIC HEAT
P265
PLUG, CONTACTOR RELAY
P266
PLUG, HEATING CONTROL
P271
PLUG, HEATING SENSORS STG 1
S15
SWITCH, LIMIT PRIMARY ELECTRIC HEAT
S20
SWITCH, LIMIT SECONDARY ELECTRIC HEAT 1
S157
SWITCH, LIMIT SECONDARY ELECTRIC HEAT 2
TB2
TERMINAL STRIP, UNIT
DESIGNATION VOLTAGE
Y 208−230/60/3
G 460/60/3
J 575/60/3
M
380−420/50/3
K15−1
K15−1
K15−1
KW HE1 HE2 HE3
072
060
036
− 048
7.5 7.5
15 15.0
22.5 15.0 7.5
30 15.0
15.0
3
1
4
6
7
3
4 7
1
