BLOWER DATA
BLOWER TABLE INCLUDES RESISTANCE FOR BASE UNIT ONLY (NO HEAT SECTION) WITH DRY INDOOR COIL AND AIR
FILTERS IN PLACE.
FOR ALL UNITS ADD:
1 − Wet indoor coil air resistance of selected unit.
2 − Any factory installed options air resistance (heat section, Economizer, etc.)
3 − Any eld installed accessories air resistance (duct resistance, di󰀨user, etc.)
See page 17 for wet coil and option/accessory air resistance data.
See page 30 for minimum air volume required for use with optional electric heat.
Maximum Static Pressure With Gas Heat - 2.0 in. w.g.
Minimum Air Volume Required For Di󰀨erent Gas Heat Sizes:
Standard - 2150 cfm; Medium - 2250 cfm; High - 2600 cfm
Total
Air Volume
cfm
Total Static Pressure - in. w.g.
0.2 0.4 0.6 0.8 1.0 1.2 1.4
RPM Watts RPM Watts RPM Watts RPM Watts RPM Watts RPM Watts RPM Watts
1750 759 223 864 298 961 359 1049 420 1128 508 1199 607 1260 704
2000 846 271 943 345 1035 410 1117 488 1189 598 1255 704 1313 804
2250 945 303 1030 391 1111 476 1184 577 1247 697 1310 806 1367 905
2500 1035 366 1109 476 1180 583 1245 688 1306 797 1368 903 1426 1008
2750 1113 476 1182 601 1248 715 1310 809 1371 902 1432 1011 1491 1129
3000 1195 596 1261 718 1324 827 1385 922 1444 1024 1503 1146 1559 1279
3250 1282 711 1346 827 1406 935 1464 1044 1521 1167 1576 1306 1629 1460
3500 1372 821 1432 940 1489 1060 1544 1192 1598 1337 1650 1494 1700 1663
3750 1461 949 1517 1081 1571 1221 1624 1373 1675 1532 1725 1700 1773 1875
4000 1549 1109 1602 1256 1653 1413 1703 1576 1753 1743 1801 1916 1847 2091
4250 1637 1298 1687 1458 1735 1625 1784 1795 1831 1966 1877 2139 1923 2310
4500 1724 1510 1772 1678 1818 1851 1864 2023 1910 2195 1955 2365 2000 2530
4750 1811 1738 1856 1910 1901 2083 1946 2254 1990 2423 2034 2587 2079 2746
5000 1897 1973 1941 2144 1985 2314 2028 2480 2071 2644 2114 2805 2158 2959
5250 1983 2205 2026 2373 2069 2538 2111 2699 2153 2860 2195 3017 - - - - - -
5500 2070 2428 2112 2595 2153 2756 2194 2912 - - - - - - - - - - - - - - - - - -
5750 2156 2643 2197 2809 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
Total
Air Volume
cfm
Total Static Pressure - in. w.g.
1.6 1.8 2.0 2.2 2.4 2.6
RPM Watts RPM Watts RPM Watts RPM Watts RPM Watts RPM Watts
1750 1316 793 1373 875 1432 963 1491 1064 1548 1175 1604 1300
2000 1368 894 1425 982 1483 1081 1540 1196 1596 1322 1650 1458
2250 1423 1001 1480 1101 1537 1216 1593 1344 1647 1483 1700 1629
2500 1483 1117 1539 1236 1594 1368 1648 1509 1700 1657 1752 1810
2750 1547 1256 1601 1394 1654 1539 1705 1690 1756 1846 1806 2004
3000 1612 1425 1664 1577 1715 1734 1765 1893 1815 2053 1864 2213
3250 1680 1623 1729 1787 1778 1949 1828 2110 1876 2269 1925 2426
3500 1748 1835 1796 2003 1844 2165 1893 2324 1942 2479 1991 2633
3750 1819 2048 1866 2214 1914 2374 1963 2530 2012 2684 2061 2837
4000 1893 2260 1940 2423 1988 2581 2036 2737 2084 2891 2134 3044
4250 1969 2475 2016 2634 2063 2790 2111 2945 2159 3098 - - - - - -
4500 2046 2689 2093 2844 2140 2998 2187 3153 - - - - - - - - - - - -
4750 2124 2900 2170 3053 - - - - - - - - - - - - - - - - - - - - - - - -
5000 2203 3111 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
5250 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
5500 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
