Page 4
Shipping and Packing List
Package 1 of 1 contains:
1- Assembled unit
Check unit for shipping damage. Receiving party should
contact last carrier immediately if shipping damage is found.
General
These instructions are intended as a general guide
and do not supersede local codes in any way.
Authorities having jurisdiction should be consulted
before installation.
The LGT092H / 150H gas/electric packaged rooftop
unit is available in 130,000, 180,000, or 240,000 Btuh
heating inputs. The LCT092H / 150H cooling
packaged rooftop unit is the same basic design as the
LGT unit except for the heating section. Optional
electric heat is factory- or field-installed in LCT units.
Units are equipped with all-aluminum condenser coils.
Units are available with an optional hot gas reheat coil
which provides dehumidifying modes of operation. Refer
to Reheat Operation section.
Units are equipped with direct drive blowers. The blower
will operate at lower speeds when demand is low and
increase to higher speeds when demand is high. Refer to
the Direct Drive Start-Up section.
The following examples show the model numbers of ten
ton units with blower options.
LGT/LCT120H4E Single Zone MSAV Direct Drive
LGT/LCT120H4P VAV Direct Drive
All units are available using R410A, an ozone-friendly HFC
refrigerant. Refer to the Cooling Start-Up section for
precautions when installing unit.
Safety
See table 1 for unit clearances.
WARNING
Electric shock hazard and danger of
explosion. Can cause injury, death or
product or property damage. Turn off
gas and electrical power to unit before
performing any maintenance or
servicing operations on the unit. Follow
lighting instructions attached to unit
when putting unit back into operation
and after service or maintenance.
UNIT CLEARANCES
C
D
B
A
FIGURE 1
Optional
Outdoor
Air Hood
TABLE 1
UNIT CLEARANCES
1
Unit
Clearance
A
in.(mm)
B
in.(mm)
C
in.(mm)
D
in.(mm)
Top
Clearance
Service
Clearance
60
(1524)
36
(914)
36
(914)
60
(1524)
Unob
structed
Clearance to
Combus
tibles
36
(914)
1 (25) 1 (25) 1 (25)
Unob
structed
Minimum
Operation
Clearance
36
(914)
36
(914)
36
(914)
36
(914)
Unob
structed
Note - Entire perimeter of unit base requires support when elevated above
mounting surface.
1
Service Clearance - Required for removal of serviceable parts.
Clearance to Combustibles - Required clearance to combustible material
(gas units). On LCT units, see clearance to combustible materials as
outlined on heater rating plate.
Minimum Operation Clearance - Required clearance for proper unit operation.
NOTICE
Roof Damage!
This system contains both refrigerant and oil.
Some rubber roofing material may absorb oil,
causing the rubber to swell. Bubbles in the rubber
roofing material can cause leaks. Protect the roof
surface to avoid exposure to refrigerant and oil
during service and installation. Failure to follow
this notice could result in damage to roof surface.
IMPORTANT
The Clean Air Act of 1990 bans the intentional vent
ing of refrigerant (CFC's and HCFC's) as of July 1,
1992. Approved methods of recovery, recycling or
reclaiming must be followed. Fines and/or incar
ceration may be levied for non-compliance.
