Page 39
K152,-1 RELAY, OUTDOOR FAN 5
K153,-1,2 RELAY, OUTDOOR FAN 6
L14 VALVE, SOLENOID REHEAT COIL 1
L30 VALVE, SOLENOID REHEAT COIL 2
P18 PLUG, EXHAUST FAN COMP
P24 PLUG, EXHAUST FAN
P47 PLUG, OUTDOOR FAN 1
P52 PLUG, OUTDOOR FAN 2
P86 PLUG, OUTDOOR FAN INTERFACE
P87 PLUG, OUTDOOR FAN INTERFACE 2
P106 PLUG, OUTDOOR FAN 3
P107 PLUG, OUTDOOR FAN 4
P108 PLUG, OUTDOOR FAN 5
P109 PLUG, OUTDOOR FAN 6
P118 PLUG, COMPRESSOR 3 AND 4, CONTROL
P119 PLUG, COMPRESSOR 3 AND 4, INPUT
P132 PLUG, EXHAUST FAN MOTOR 1
P133 PLUG, EXHAUST FAN MOTOR 2
P138 PLUG, EXHAUST FAN 2
P263 PLUG, HIGH AND LOW PRESSURE SWITCHES
P264 PLUG, BLOWER DECK
P265 PLUG, CONTACTORS AND RELAYS
P267 PLUG,OUTDOOR FAN AREA
P268 PLUG, TRANSFORMERS
P269 PLUG, HUMIDITROL
P299 PLUG, SAFETY
PT5 PRESSURE TRANSDUCER, ECONOMIZER
RT17 SENSOR, OUTDOOR AIR
S4 SWITCH, LIMIT HI PRESS COMPRESS 1
S7 SWITCH, LIMIT HI PRESS COMPRESS 2
S11 SWITCH, LOW PRESS, LOW AMBIENT KIT COMP 1
S28 SWITCH, LIMIT HI PRESS COMPRESS 3
S42 SWITCH, OVERLOAD RELAY BLOWER MOTOR
S48 SWITCH, DISCONNECT
S49 SWITCH, FREEZE STAT COMPRESS 1
S50 SWITCH, FREEZE STAT COMPRESS 2
S53 SWITCH, FREEZE STAT COMPRESS 3
S84 SWITCH, LOW PRESS, LOW AMBIENT KIT COMP 2
S85 SWITCH, LOW PRESS, LOW AMBIENT KIT COMP 3
S87 SWITCH, LOW PRESS, COMP 1
S88 SWITCH, LOW PRESS, COMP 2
S94 SWITCH, LOW PRESS, LOW AMBIENT KIT COMP 4
S95 SWITCH, FREEZE STAT COMPRESS 4
S96 SWITCH, LIMIT HI PRESS COMPRESS 4
S97 SWITCH, LOW PRESS, COMP 4
S98 SWITCH, LOW PRESS, COMP 3
