Page 15
507124-04 3/2016
FIGURE 15
PULLEY ALIGNMENT - NO TENSIONER
BELT
BLOWER
PULLEY
MOTOR
PULLEY
NOT ALIGNED
ALIGNED
BELT
BLOWER
PULLEY
MOTOR
PULLEY
NOT ALIGNED
ALIGNED
TENSIONER
PULLEY ALIGNMENT - WITH TENSIONER
FIGURE 16
BOLT
PULLEY ALIGNMENT - WITH TENSIONER
FIGURE 17
NUT
ALIGN
TENSIONER
MARKS
ADJUSTABLE
PULLEY
FIXED
PULLEY
TENSIONER
TENSIONER BOLT AND
ADJUSTMENT NUT
