BLOWER DATA 0.5 HP | 3 ROW (024, 036)
BLOWER TABLE INCLUDES RESISTANCE FOR BASE UNIT ONLY WITH DRY INDOOR COIL AND AIR FILTERS IN PLACE. FOR ALL UNITS ADD: 1 - Any factory installed options air resistance (heat section, economizer, etc.). 2 - Any eld installed accessories air resistance (duct resistance, di󰀨user, etc.).
Minimum Air Volume Required For Di󰀨erent Gas Heat Sizes: Standard Heat - 1075 cfm; Medium Heat - 1150 cfm; High Heat - 1500 cfm
See page 23 for wet coil and options/accessory air resistance data. DOWNFLOW
External
Static
Press.
in. w.g.
Percentage of Total Motor Torque
20% 30% 40% 50% 60% 70% 80% 90% 100%
Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM
0 819 47 403 1006 79 463 1192 111 523 1335 152 573 1477 193 622 1580 236 661 1682 279 699 1812 353 753 1876 400 783
0.1 723 48 485 919 82 539 1114 116 593 1264 159 637 1414 202 681 1522 246 715 1629 290 749 1767 365 797 1835 414 824 0.2 636 51 565 840 88 613 1044 124 660 1201 169 699 1357 213 738 1470 258 769 1582 303 799 1726 380 841 1797 429 865 0.3 557 57 641 769 96 683 981 134 725 1144 180 760 1306 226 794 1423 273 821 1540 319 848 1689 397 885 1761 446 906 0.4 485 65 713 704 106 750 923 146 787 1091 194 818 1259 241 848 1380 289 872 1500 336 895 1653 415 929 1725 463 948 0.5 418 73 783 644 116 815 870 158 846 1043 207 873 1215 256 900 1339 305 921 1462 353 942 1618 433 973 1689 481 991 0.6 355 82 849 587 127 876 819 171 903 996 222 927 1173 272 950 1299 321 969 1425 370 987 1582 451 1016 1651 499 1034 0.7 - - - - - - - - - - - - - - - - - - 769 184 957 950 236 978 1131 287 998 1259 337 1015 1387 387 1032 1544 468 1058 1610 516 1077 0.8 - - - - - - - - - - - - - - - - - - 720 195 1008 904 248 1026 1088 301 1044 1218 352 1060 1347 403 1075 1503 484 1101 1565 531 1121 0.9 - - - - - - - - - - - - - - - - - - 670 206 1057 857 260 1073 1043 314 1088 1173 366 1102 1303 417 1116 1458 498 1142 - - - - - - - - - 1.0 - - - - - - - - - - - - - - - - - - 617 214 1102 806 269 1116 994 324 1130 1125 376 1144 1255 428 1157 1406 510 1184 - - - - - - - - - 1.1 - - - - - - - - - - - - - - - - - - 561 219 1145 751 276 1157 941 332 1169 1071 384 1183 1200 436 1196 1347 518 1225 - - - - - - - - - 1.2 - - - - - - - - - - - - - - - - - - 500 221 1185 691 278 1196 881 335 1207 1010 388 1221 1139 441 1234 1280 522 1265 - - - - - - - - - 1.3 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 814 335 1242 942 388 1256 1069 441 1270 - - - - - - - - - - - - - - - - - - 1.4 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 738 330 1276 864 384 1291 989 437 1305 - - - - - - - - - - - - - - - - - -
HORIZONTAL
External
Static
Press.
in. w.g.
Percentage of Total Motor Torque
20% 30% 40% 50% 60% 70% 80% 90% 100%
Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM
0 794 45 388 970 76 454 1146 107 519 1281 149 575 1416 191 630 1522 110 678 1627 293 726 1715 351 768 1802 408 810
0.1 709 44 460 895 78 519 1080 111 577 1223 155 627 1366 199 677 1477 251 721 1588 303 764 1681 362 804 1773 420 843 0.2 630 46 531 855 82 583 1019 117 634 1169 163 679 1318 208 723 1435 262 763 1552 315 803 1648 375 841 1743 434 878 0.3 556 51 602 759 88 646 961 125 690 1117 172 730 1273 219 769 1395 274 805 1516 328 841 1615 388 877 1714 448 912 0.4 486 58 671 696 97 709 906 135 746 1068 184 781 1230 232 815 1356 288 848 1481 343 880 1582 403 914 1683 463 948 0.5 420 66 740 637 107 771 854 147 802 1021 196 831 1188 245 860 1317 301 890 1446 357 919 1549 418 951 1652 478 983 0.6 - - - - - - - - - - - - - - - - - - 804 159 856 946 209 881 1147 259 905 1279 316 932 1410 372 958 1514 432 989 1618 492 1019 0.7 - - - - - - - - - - - - - - - - - - 756 172 910 932 223 930 1107 273 949 1241 330 973 1374 386 996 1478 446 1026 1582 506 1055 0.8 - - - - - - - - - - - - - - - - - - 709 185 962 888 236 978 1066 287 993 1201 344 1014 1336 400 1034 1440 460 1063 1544 519 1091 0.9 - - - - - - - - - - - - - - - - - - 663 197 1013 844 249 1025 1025 300 1036 1161 357 1054 1296 413 1072 1399 472 1100 1502 530 1127 1.0 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 982 313 1078 1118 369 1094 1254 424 1109 1355 482 1136 1456 540 1163 1.1 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 938 323 1119 1073 379 1133 1208 434 1146 1307 491 1172 1406 548 1198 1.2 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 892 332 1158 1026 387 1170 1159 441 1182 1255 497 1208 1351 553 1233 1.3 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 843 340 1197 975 393 1207 1106 446 1216 1198 501 1242 1290 555 1268 1.4 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 790 344 1234 920 396 1242 1049 448 1250 1137 501 1276 1224 553 1302
