BLOWER DATA 1.0 HP | 3 ROW (048)
BLOWER TABLE INCLUDES RESISTANCE FOR BASE UNIT ONLY WITH DRY INDOOR COIL AND AIR FILTERS IN PLACE.
FOR ALL UNITS ADD:
1 - Any factory installed options air resistance (heat section, economizer, etc.).
2 - Any eld installed accessories air resistance (duct resistance, di󰀨user, etc.).
Minimum Air Volume Required For Di󰀨erent Gas Heat Sizes:
Standard Heat - 1075 cfm; Medium Heat - 1150 cfm; High Heat - 1500 cfm
See page 23 for wet coil and options/accessory air resistance data.
DOWNFLOW
External
Static
Press.
in. w.g.
Percentage of Total Motor Torque
20% 30% 40% 50% 60% 70% 80% 90% 100%
Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM
0 1115 124 488 1344 200 572 1573 276 655 1747 377 724 1920 477 792 2041 581 844 2161 684 896 2304 852 964 2354 936 992
0.1 1012 101 536 1253 181 614 1493 261 691 1677 366 755 1860 471 819 1990 578 868 2119 685 916 2277 860 980 2339 951 1006
0.2 926 88 584 1177 172 656 1427 256 728 1619 365 788 1811 473 848 1949 583 894 2086 693 939 2256 873 999 2328 969 1024
0.3 854 86 634 1113 173 701 1372 260 767 1572 371 823 1772 482 878 1916 595 921 2059 707 963 2240 891 1019 2319 991 1043
0.4 794 91 684 1061 181 746 1328 270 807 1535 383 859 1741 496 910 1890 611 950 2038 725 989 2226 913 1042 2311 1014 1065
0.5 745 104 734 1019 195 791 1292 286 847 1504 401 895 1715 515 942 1868 631 979 2020 747 1016 2214 936 1066 2301 1039 1089
0.6 704 122 785 983 215 837 1262 307 888 1478 423 932 1693 538 976 1849 654 1011 2004 770 1045 2201 960 1092 2288 1063 1114
0.7 671 145 836 954 238 883 1237 331 929 1456 447 969 1674 562 1009 1831 678 1041 1988 794 1073 2185 983 1118 2270 1085 1140
0.8 643 171 886 929 264 928 1215 357 969 1435 472 1006 1655 587 1043 1813 703 1073 1970 818 1103 2164 1005 1145 2246 1104 1168
0.9 619 199 935 907 291 973 1194 383 1010 1415 498 1043 1635 612 1076 1792 726 1104 1948 840 1132 2138 1024 1173 2212 1119 1196
1.0 596 228 983 884 319 1016 1172 410 1049 1392 523 1079 1612 635 1109 1766 747 1135 1920 859 1161 2104 1038 1200 - - - - - - - - -
1.1 - - - - - - - - - - - - - - - - - - 1148 434 1087 1366 545 1115 1583 655 1142 1734 765 1166 1885 874 1189 2060 1047 1227 - - - - - - - - -
1.2 - - - - - - - - - - - - - - - - - - 1120 456 1124 1334 564 1149 1548 671 1173 1695 777 1195 1841 883 1217 2004 1050 1254 - - - - - - - - -
1.3 - - - - - - - - - - - - - - - - - - 1085 474 1159 1295 578 1181 1505 681 1202 1646 784 1223 1786 886 1244 1935 1044 1280 - - - - - - - - -
1.4 - - - - - - - - - - - - - - - - - - 1043 486 1192 1247 586 1211 1451 685 1230 1585 783 1250 1718 881 1269 1851 1029 1305 - - - - - - - - -
HORIZONTAL
External
Static
Press.
in. w.g.
Percentage of Total Motor Torque
20% 30% 40% 50% 60% 70% 80% 90% 100%
Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM
0 1087 111 493 1304 184 579 1520 257 665 1689 368 738 1857 478 810 1972 588 864 2087 698 918 2196 844 975 2283 925 1000
0.1 1021 104 537 1246 180 618 1470 255 699 1646 368 768 1821 480 837 1941 592 888 2061 704 938 2179 852 992 2255 926 1017
0.2 961 102 582 1193 181 658 1425 259 734 1607 373 799 1789 487 864 1914 601 912 2039 714 960 2163 864 1012 2231 932 1034
0.3 906 106 628 1145 186 699 1384 266 769 1572 382 831 1759 498 892 1889 613 938 2018 728 984 2149 879 1033 2209 941 1053
0.4 855 113 674 1101 196 740 1347 278 806 1540 396 864 1732 513 921 1866 629 965 1999 744 1008 2134 896 1054 - - - - - - - - -
0.5 808 125 720 1060 209 781 1312 293 842 1509 412 896 1706 530 950 1843 646 992 1980 762 1033 2119 915 1077 - - - - - - - - -
0.6 764 139 766 1022 225 823 1279 310 879 1481 430 930 1682 549 980 1821 666 1019 1960 782 1058 2102 935 1101 - - - - - - - - -
0.7 722 155 812 985 242 864 1247 328 916 1452 449 964 1657 569 1011 1799 686 1048 1940 803 1084 2084 955 1125 - - - - - - - - -
0.8 682 172 858 949 260 906 1216 348 953 1424 469 997 1632 589 1041 1776 706 1076 1919 823 1111 2063 974 1150 - - - - - - - - -
0.9 643 191 903 914 279 946 1185 367 989 1396 489 1030 1606 610 1071 1751 727 1104 1895 843 1137 2039 992 1175 - - - - - - - - -
1.0 - - - - - - - - - - - - - - - - - - 1153 386 1024 1366 508 1062 1579 629 1100 1724 745 1132 1869 861 1163 2011 1008 1201 - - - - - - - - -
1.1 - - - - - - - - - - - - - - - - - - 1120 404 1059 1334 525 1095 1548 646 1130 1694 761 1160 1839 876 1189 1979 1021 1226 - - - - - - - - -
1.2 - - - - - - - - - - - - - - - - - - 1085 420 1093 1300 541 1126 1515 661 1158 1660 775 1186 1805 889 1214 1941 1031 1250 - - - - - - - - -
1.3 - - - - - - - - - - - - - - - - - - 1047 433 1126 1263 553 1156 1478 672 1186 1622 785 1213 1766 898 1239 1897 1037 1275 - - - - - - - - -
1.4 - - - - - - - - - - - - - - - - - - 1005 442 1158 1221 561 1185 1436 680 1212 1579 792 1238 1721 903 1263 1847 1037 1298 - - - - - - - - -
