BLOWER DATA 1.0 HP | 4 ROW (060)
BLOWER TABLE INCLUDES RESISTANCE FOR BASE UNIT ONLY WITH DRY INDOOR COIL AND AIR FILTERS IN PLACE.
FOR ALL UNITS ADD:
1 - Any factory installed options air resistance (heat section, economizer, etc.).
2 - Any eld installed accessories air resistance (duct resistance, di󰀨user, etc.).
Minimum Air Volume Required For Di󰀨erent Gas Heat Sizes:
Standard Heat - 1075 cfm; Medium Heat - 1150 cfm; High Heat - 1500 cfm
See page 23 for wet coil and options/accessory air resistance data.
DOWNFLOW
External
Static
Press.
in. w.g.
Percentage of Total Motor Torque
20% 30% 40% 50% 60% 70% 80% 90% 100%
Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM
0 1101 120 494 1328 196 578 1555 272 662 1728 374 731 1901 475 800 2023 580 852 2145 684 903 2292 854 970 2348 942 998
0.1 1002 99 541 1241 180 620 1479 260 698 1662 366 763 1845 471 827 1976 579 876 2106 687 924 2268 865 987 2334 958 1013
0.2 918 88 589 1167 173 663 1416 257 736 1608 366 796 1800 475 856 1938 586 902 2076 697 947 2249 880 1006 2324 978 1031
0.3 848 86 638 1106 174 706 1364 261 774 1564 373 830 1763 485 886 1907 599 929 2051 712 972 2234 899 1028 2316 1000 1052
0.4 790 92 688 1056 183 751 1321 273 814 1527 387 866 1733 501 918 1882 617 958 2031 732 998 2221 921 1051 2307 1024 1074
0.5 742 105 738 1015 197 796 1287 289 854 1498 405 902 1709 520 950 1862 637 988 2014 754 1025 2208 944 1076 2296 1048 1099
0.6 703 124 788 981 217 841 1258 310 894 1473 427 939 1688 543 984 1843 660 1019 1998 777 1053 2194 968 1101 2281 1071 1124
0.7 670 146 838 952 240 887 1233 334 935 1451 451 976 1669 568 1017 1826 685 1050 1982 801 1082 2177 991 1128 2260 1092 1151
0.8 642 172 888 927 266 932 1211 360 975 1431 477 1013 1650 593 1051 1807 709 1081 1963 825 1111 2155 1012 1155 2233 1109 1178
0.9 618 200 937 904 294 976 1190 387 1015 1410 502 1050 1629 617 1084 1785 732 1112 1940 846 1140 2127 1029 1182 - - - - - - - - -
1.0 595 229 985 882 321 1020 1168 413 1054 1387 526 1086 1605 639 1117 1758 752 1143 1911 864 1169 2090 1042 1209 - - - - - - - - -
1.1 - - - - - - - - - - - - - - - - - - 1144 437 1092 1360 548 1120 1576 659 1148 1725 769 1173 1874 878 1197 2043 1049 1236 - - - - - - - - -
1.2 - - - - - - - - - - - - - - - - - - 1115 458 1129 1328 566 1154 1540 674 1179 1685 780 1202 1829 886 1225 1985 1049 1262 - - - - - - - - -
1.3 - - - - - - - - - - - - - - - - - - 1080 475 1163 1288 579 1186 1496 683 1208 1634 785 1230 1772 887 1251 1913 1042 1288 - - - - - - - - -
1.4 - - - - - - - - - - - - - - - - - - 1037 487 1196 1239 587 1216 1441 686 1236 1572 783 1256 1703 880 1275 1826 1024 1312 - - - - - - - - -
HORIZONTAL
External
Static
Press.
in. w.g.
Percentage of Total Motor Torque
20% 30% 40% 50% 60% 70% 80% 90% 100%
Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM Cfm Watts RPM
0 1077 113 502 1282 175 585 1486 237 668 1670 363 746 1854 489 823 1993 623 884 2131 757 944 2216 882 995 2268 926 1009
0.1 1016 109 546 1227 172 624 1437 234 701 1626 361 775 1814 488 848 1956 623 906 2098 757 964 2194 887 1011 2242 928 1026
0.2 962 111 591 1177 174 663 1392 236 735 1585 364 805 1777 492 874 1923 627 930 2069 762 985 2175 895 1029 2218 935 1044
0.3 913 118 636 1133 181 703 1352 244 770 1548 372 836 1744 500 902 1893 636 955 2042 772 1007 2157 907 1048 2196 945 1063
0.4 868 130 682 1092 193 744 1315 256 806 1515 384 868 1714 512 930 1866 648 980 2018 784 1030 2139 922 1069 - - - - - - - - -
0.5 827 146 728 1054 209 785 1281 271 842 1484 399 901 1687 526 959 1841 663 1007 1995 799 1054 2121 938 1090 - - - - - - - - -
0.6 789 165 775 1019 227 827 1249 288 879 1455 416 934 1660 543 988 1816 679 1034 1972 815 1079 2102 955 1113 - - - - - - - - -
0.7 752 185 821 986 247 869 1219 308 916 1427 435 967 1634 562 1018 1792 698 1061 1949 833 1104 2081 972 1136 - - - - - - - - -
0.8 718 208 867 954 268 910 1189 328 953 1399 455 1000 1608 581 1047 1767 716 1088 1925 851 1129 2058 989 1160 - - - - - - - - -
0.9 684 231 913 922 290 951 1160 349 989 1371 475 1033 1581 600 1077 1741 734 1116 1900 868 1154 2031 1004 1185 - - - - - - - - -
1.0 - - - - - - - - - - - - - - - - - - 1129 369 1025 1341 494 1066 1553 618 1106 1713 751 1143 1872 884 1179 2001 1017 1209 - - - - - - - - -
1.1 - - - - - - - - - - - - - - - - - - 1097 388 1060 1310 511 1098 1522 634 1135 1682 766 1170 1841 898 1204 1966 1028 1233 - - - - - - - - -
1.2 - - - - - - - - - - - - - - - - - - 1063 405 1095 1276 527 1129 1488 648 1163 1647 779 1196 1806 909 1228 1925 1034 1257 - - - - - - - - -
1.3 - - - - - - - - - - - - - - - - - - 1026 420 1128 1239 540 1159 1451 659 1190 1609 788 1221 1767 917 1252 1879 1036 1281 - - - - - - - - -
1.4 - - - - - - - - - - - - - - - - - - 985 431 1160 1197 548 1188 1409 665 1216 1566 793 1245 1723 920 1274 1825 1033 1304 - - - - - - - - -
