BLOWER DATA 1.5 HP | 4 ROW (060)
BLOWER TABLE INCLUDES RESISTANCE FOR BASE UNIT ONLY WITH DRY INDOOR COIL AND AIR FILTERS IN PLACE.
FOR ALL UNITS ADD:
1 - Any factory installed options air resistance (heat section, economizer, etc.).
2 - Any eld installed accessories air resistance (duct resistance, diuser, etc.).
Minimum Air Volume Required For Dierent Gas Heat Sizes:
Standard Heat - 1075 cfm; Medium Heat - 1150 cfm; High Heat - 1500 cfm
See page 23 for wet coil and options/accessory air resistance data.
DOWNFLOW
Total
Air
cfm
Total Static Pressure - in. w.g.
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0 1.1 1.2 1.3
RPM Watts RPM Watts RPM Watts RPM Watts RPM Watts RPM Watts RPM Watts RPM Watts RPM Watts RPM Watts RPM Watts RPM Watts RPM Watts
400 720 20 805 41 880 60 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
600 849 51 933 73 1011 93 1083 112 1152 128 1229 130 1310 126 1389 125 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
800 978 81 1064 103 1145 124 1220 144 1291 162 1367 170 1443 175 1514 183 1578 198 1634 222 1684 252 1734 281 1783 309
1000 1147 116 1225 138 1302 159 1376 179 1446 198 1517 211 1586 224 1648 242 1703 266 1753 296 1801 327 1849 356 1896 382
1200 1347 154 1418 175 1487 196 1555 216 1620 235 1684 253 1743 275 1795 302 1841 336 1884 373 1930 405 1976 433 2021 458
1400 1571 182 1629 209 1686 236 1742 262 1798 288 1850 315 1899 346 1943 380 1984 417 2025 453 2068 485 2113 512 2156 537
1600 1753 252 1803 286 1853 318 1902 351 1951 383 1998 415 2043 447 2087 478 2130 508 2173 539 2216 568 2259 595 2302 621
1800 1935 339 1983 371 2030 403 2076 434 2122 465 2167 495 2210 524 2253 554 2295 586 2337 618 2378 650 2418 682 2458 714
2000 2127 415 2172 448 2217 481 2260 513 2303 546 2345 579 2385 614 2425 653 2464 693 2503 734 2541 774 2578 814 2614 855
2200 2321 507 2363 545 2404 583 2444 623 2484 664 2522 707 2560 753 2596 801 2632 848 2667 895 2703 939 2737 981 2770 1023
2400 2516 635 2556 679 2594 723 2631 767 2668 813 2703 861 2737 909 2772 958 2805 1005 2839 1050 2872 1093 2905 1135 2936 1176
2600 2715 796 2751 841 2786 887 2820 933 2854 980 2887 1027 2919 1074 2952 1120 2983 1164 3015 1207 3046 1249 3077 1290 3107 1330
2800 2915 970 2947 1016 2979 1062 3011 1107 3042 1152 3073 1197 3104 1240 3134 1282 3164 1323 3193 1364 3222 1404 3251 1445 3280 1485
3000 3112 1142 3142 1187 3172 1232 3202 1276 3232 1319 3261 1361 3289 1401 3317 1441 3344 1480 3371 1520 3399 1560 3426 1600 3453 1638
Total
Air cfm
Total Static Pressure - in. w.g.
1.4 1.5 1.6 1.7 1.8 1.9 2.0
RPM Watts RPM Watts RPM Watts RPM Watts RPM Watts RPM Watts RPM Watts
800 1830 335 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
1000 1940 405 1983 426 2026 446 2068 466 2111 488 2154 512 2196 536
1200 2064 480 2106 501 2148 522 2190 544 2232 569 2273 595 2314 623
1400 2199 560 2241 584 2282 608 2323 634 2363 664 2402 694 2440 726
1600 2344 647 2384 675 2424 706 2462 740 2498 776 2535 811 2571 848
1800 2497 749 2533 788 2568 829 2602 872 2636 914 2671 953 2705 992
2000 2648 898 2681 941 2714 986 2746 1030 2779 1072 2812 1112 2845 1152
2200 2803 1064 2835 1105 2867 1145 2899 1186 2931 1225 2964 1265 2995 1303
2400 2968 1217 2999 1258 3031 1298 3062 1337 3093 1377 3124 1415 3156 1454
2600 3138 1371 3168 1411 3199 1450 3229 1489 3260 1528 3290 1566 3321 1604
2800 3309 1524 3338 1563 3368 1602 3398 1640 3428 1678 3458 1717 3488 1755
3000 3481 1677 3508 1715 3537 1752 3566 1790 3595 1828 3625 1866 3655 1904
