BLOWER DATA 1.5 HP | 4 ROW (060)
BLOWER TABLE INCLUDES RESISTANCE FOR BASE UNIT ONLY WITH DRY INDOOR COIL AND AIR FILTERS IN PLACE.
FOR ALL UNITS ADD:
1 - Any factory installed options air resistance (heat section, economizer, etc.).
2 - Any eld installed accessories air resistance (duct resistance, diuser, etc.).
Minimum Air Volume Required For Dierent Gas Heat Sizes:
Standard Heat - 1075 cfm; Medium Heat - 1150 cfm; High Heat - 1500 cfm
See page 23 for wet coil and options/accessory air resistance data.
HORIZONTAL
Total
Air
cfm
Total Static Pressure - in. w.g.
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0 1.1 1.2 1.3
RPM Watts RPM Watts RPM Watts RPM Watts RPM Watts RPM Watts RPM Watts RPM Watts RPM Watts RPM Watts RPM Watts RPM Watts RPM Watts
400 711 16 796 38 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
600 840 47 924 66 1006 83 1083 96 1154 107 1226 109 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
800 990 76 1072 94 1153 111 1230 126 1301 140 1372 148 1441 155 1503 165 1560 181 1612 203 1661 229 - - - - - - - - - - - -
1000 1179 108 1253 126 1326 144 1397 161 1464 178 1530 194 1590 210 1646 231 1696 255 1744 283 1790 312 1836 340 1880 365
1200 1388 146 1454 166 1519 186 1582 207 1641 228 1697 251 1749 276 1797 305 1842 336 1885 367 1929 397 1973 424 2016 450
1400 1606 189 1661 216 1715 242 1768 270 1818 298 1866 328 1911 358 1953 390 1995 420 2037 449 2079 476 2121 503 2163 527
1600 1794 268 1842 301 1890 333 1938 364 1984 396 2029 426 2073 453 2115 479 2157 503 2199 528 2240 553 2281 581 2321 609
1800 1991 364 2035 395 2079 426 2123 456 2167 486 2210 515 2252 541 2294 568 2334 596 2374 625 2412 657 2448 692 2484 727
2000 2202 451 2242 482 2283 513 2323 545 2363 577 2402 611 2440 646 2477 683 2512 722 2546 763 2579 804 2613 844 2645 884
2200 2408 559 2446 596 2483 633 2520 672 2555 712 2590 753 2623 796 2655 841 2686 885 2717 928 2748 970 2780 1010 2812 1050
2400 2609 703 2644 744 2678 786 2711 829 2744 872 2776 916 2806 961 2835 1006 2865 1050 2895 1092 2925 1133 2955 1172 2985 1212
2600 2808 874 2840 916 2871 959 2902 1003 2932 1046 2961 1090 2990 1133 3019 1176 3048 1217 3077 1257 3106 1297 3135 1336 3164 1374
2800 3006 1054 3035 1096 3064 1139 3092 1181 3121 1223 3149 1265 3177 1305 3205 1344 3234 1383 3262 1421 3290 1460 3317 1498 3345 1536
3000 3202 1228 3229 1270 3257 1312 3284 1353 3312 1394 3339 1433 3366 1472 3393 1509 3419 1547 3446 1584 3472 1622 3499 1660 3525 1698
Total
Air cfm
Total Static Pressure - in. w.g.
1.4 1.5 1.6 1.7 1.8 1.9 2.0
RPM Watts RPM Watts RPM Watts RPM Watts RPM Watts RPM Watts RPM Watts
800 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
1000 1923 389 1964 411 2004 431 2043 450 2083 468 - - - - - - - - - - - -
1200 2057 473 2097 494 2136 514 2176 534 2215 553 2254 574 2293 596
1400 2205 549 2245 571 2284 594 2322 618 2360 644 2396 672 2432 702
1600 2360 637 2398 667 2434 699 2468 733 2501 768 2532 805 2563 842
1800 2519 763 2552 801 2583 840 2614 879 2644 918 2674 957 2704 995
2000 2677 924 2708 963 2739 1003 2769 1041 2799 1080 2829 1118 2859 1155
2200 2842 1089 2873 1127 2902 1166 2932 1203 2962 1241 2991 1278 3021 1315
2400 3015 1250 3044 1289 3074 1327 3103 1364 3132 1402 3162 1439 3192 1476
2600 3192 1412 3221 1450 3250 1488 3279 1525 3308 1562 3337 1599 3367 1635
2800 3372 1574 3400 1611 3428 1648 3456 1685 3485 1721 3514 1758 3543 1794
3000 3552 1735 3578 1772 3605 1808 3633 1844 3660 1880 3689 1916 3717 1952
