50
Installation and Maintenance
Service Manual
a
b
c
Steps
Procedure
8.Remove earthing wire
9.Remove electric box cover
screw
clasp
clasp
electric box cover
Remove earthing screws, and then remove
the earthing wire.
Loosen clasps at the left side of electric box.
Loosen clasps on the right side of electric box.
Remove electric box cover.
