51
Installation and Maintenance
Service Manual
a
b
c
ProcedureSteps
10.Remove temperature sensor
11.Remove electric box
temperature sensor
screw
electric box
Pull out the indoor temperature sensor.
Pull out 6 sockets on PCB board.
Pull out two screws on electric box.
Remove the electric box.
