Lennox LRP14GE Series User Manual

Page 11
ELECTRIC HEAT DATA — LRP14AC Only
Model No.LRP14AC24 LRP14AC30 LRP14AC36
208/230V 208/230V 208/230V
Compressor
Rated Load Amps 10.9 13.5 15.4
Locked Rotor Amps59.3 72.5 83.9
Outdoor Fan
Motor
Full Load Amps 1.0 1.0 1.0
Locked Rotor Amps1.9 1.9 1.9
Indoor
Blower Motor
Rated Load Amps 2.8 2.8 4.1
Locked Rotor Amps3.9 3.9 4.4
1
Maximum
Overcurrent
Protection
Voltage 208V 240V 208V 240V 208V 240V
Unit only, no electric heat 25 25 30 30 30 30
5 kW 25 30 25 30 25 30
7.5 kW 40 45 40 45 40 45
10 kW 50 60 50 60 50 60
15 kW
Circuit 1 - - - - - - 50 60 50 60
Circuit 2- - - - - - 25 30 25 30
1
Maximum Overcurrent
Protection with Optional
Single-Point Power
Supply
5 kW 25 30 30 30 30 30
7.5 kW 40 45 40 45 40 45
10 kW 50 60 50 60 50 60
15 kW - - - - - - 70 80 70 90
2
Minimum
Circuit
Ampacity
Unit only, no electric heat 16.7 16.7 18.7 18.7 20.6 20.6
5 kW 24.3 27.7 24.3 27.7 24.6 28
7.5 kW 35.6 40.8 35.6 40.8 35.9 41.1
10 kW 46.8 53.8 46.8 53.8 47.1 54.1
15 kW
Circuit 1 - - - - - - 46.8 53.8 47.1 54.1
Circuit 2- - - - - - 22.6 26 22.6 26
2
Minimum Circuit
Ampacity with Optional
Single-Point Power
Supply
5 kW 24.3 27.7 24.3 27.7 24.6 28
7.5 kW 35.6 40.8 35.6 40.8 35.9 41.1
10 kW 46.8 53.8 46.8 53.8 47.1 54.1
15 kW - - - - - - 69.4 79.8 69.7 80.1
NOTE - All units have a minimum Short Circuit Current Rating (SCCR) of 5000 amps.
NOTE - Extremes of operating range are plus and minus 10% of line voltage.
1
HACR type breaker or fuse.
2
3
A separate compressor circuit is required.
