Lennox LRP14GE Series User Manual

Page 16
Typical Parts Arrangement
CONDENSER FAN
ASSEMBLY
CONDENSER COIL
HEATING COMPARTMENT
BLOWER
COMPARTMENT
CONTROL BOX
VENT HOOD
(GE/GN ONLY)
COMPRESSOR
COMPARTMENT
CONDENSATE
PAN and DRAIN
HEAT EXCHANGER
ACCESS DOOR
COMBUSTION AIR OPENING
(GE/GN UNITS)
FIGURE 1. Typical Parts Arrangement – LRP14GE / LRP14GN
DEFROST CONTROL
HP OR BLOWER
MOTOR CONTROL
BOARD (LRP16 ONLY)
TRANSFORMER
CONTACTOR
IGNITION CONTROL
(GE/GN ONLY)
PRESSURE SWITCH
CAPACITOR
LOW VOLTAGE
CONNECTION BOX
(AC UNIT ONLY)
FIGURE 2. Typical Control Box
