Blower Data – LRP16GE / LRP16GX
LRP16GE24, LRP16GX24 Blower Performance
0 through 0.80 in. w.g. External Static Pressure Range
“ADJUST”
Jumper
Setting
Blower Control Jumper Speed Positions
“COOL” Speed - cfm “HEAT” Speed - cfm“CONTINUOUS FAN” Speed - cfm
ABCDABCDAB
CD
+1100 880 660 440 1100 1000 900815 550440 330220
NORM 1000 800 600 400 1100 1000 900815 500400 300200
— 900 720 540 360 1100 1000 900815 450360 270180
LRP16GE36, LRP16GX36 Blower Performance
0 through 0.80 in. w.g. External Static Pressure Range
“ADJUST”
Jumper
Setting
Blower Control Jumper Speed Positions
“COOL” Speed - cfm “HEAT” Speed - cfm“CONTINUOUS FAN” Speed - cfm
ABCDABCDAB
CD
+ 1540 1320 1100 880 1400 1200 1100 975770 660550 440
NORM 1400 1200 1000 800 1400 1200 1100 975700 600500 400
— 1260 1080 900 720 1400 1200 1100 975630 540450 360
LRP16GE48, LRP16GX48 Blower Performance
0 through 0.80 in. w.g. External Static Pressure Range
“ADJUST”
Jumper
Setting
Blower Control Jumper Speed Positions
“COOL” Speed - cfm “HEAT” Speed - cfm“CONTINUOUS FAN” Speed - cfm
ABCDABCDAB
CD
+ 1980 1760 1540 1320 1350 1200 1100 1000 990880 770660
NORM 1800 1600 1400 1200 1350 1200 1100 1000 900800 700600
— 1620 1440 1260 1080 1350 1200 1100 1000 810720 630540
LRP16GE60, LRP16GX60 Blower Performance
0 through 0.80 in. w.g. External Static Pressure Range
“ADJUST”
Jumper
Setting
Blower Control Jumper Speed Positions
“COOL” Speed - cfm “HEAT” Speed - cfm“CONTINUOUS FAN” Speed - cfm
ABCDABCDAB
CD
+ 2200 1980 1760 1540 1480 1380 1280 1180 1100 990880 770
NORM 2000 1800 1600 1400 1480 1380 1280 1180 1000 900800 700
— 1800 1620 1440 1260 1480 1380 1280 1180 900810 720630
