Page 14
ELECTRIC HEAT DATA — LRP16HP Only
Model No. LRP16HP24 LRP16HP36 LRP16HP48 LRP16HP60
208/230V 208/230V 208/230V 208/230V
Compressor
Rated Load Amps 11.7 16.1 21.2 27.1
Locked Rotor Amps 58.3 83.0 104.0 152.9
Outdoor Fan Motor Full Load Amps 1.2 1.4 2.3 2.4
Indoor
Blower Motor
Full Load Amps 1.7 3.6 4.5 5.5
1
Maximum
Overcurrent
Protection
Voltage 208V 240V 208V 240V 208V 240V 208V 240V
Unit only, no electric heat 25 25 40 40 50 50 60 60
5 kW 25 30 30 35 30 35 35 35
7.5 kW 40 45 40 45 40 45 45 50
10 kW 50 60 50 60 60 60 60 60
15 kW
Circuit 1 - - - - - - 50 60 60 60 60 60
Circuit 2 - - - - - - 25 30 25 30 25 30
20 kW Circuit 1 - - - - - - - - - - - - 60 60 60 60
Circuit 2 - - - - - - - - - - - - 50 60 50 60
1
Maximum Overcurrent
Protection with Optional
Single-Point Power
Supply
5 kW 45 50 50 60 70 70 80 90
7.5 kW 60 60 60 70 80 80 90 100
10 kW 70 80 80 80 90 90 100 110
15 kW - - - - - - 100 110 110 125 110 125
20 kW - - - - - - - - - - - - 125 150 150 150
2
Minimum
Circuit
Ampacity
Unit only, no electric heat 18.0 18.0 25.6 25.6 33.8 33.8 42.3 42.3
5 kW 24.7 28.2 27.1 30.5 28.2 31.7 29.5 32.9
7.5 kW 36.0 41.2 38.3 43.6 39.5 44.7 40.7 45.9
10 kW 47.3 54.2 49.6 56.6 50.8 57.7 52.0 59.0
15 kW
Circuit 1 - - - - - - 49.6 56.6 50.8 57.7 52.0 59.0
Circuit 2 - - - - - - 22.6 26.0 22.6 26.0 22.6 26.0
20 kW Circuit 1 - - - - - - - - - - - - 50.8 57.7 52.0 59.0
Circuit 2 - - - - - - - - - - - - 45.1 52.1 45.1 52.1
2
Minimum Circuit
Ampacity with Optional
Single-Point Power
Supply
5 kW 40.6 44.0 48.2 51.6 56.4 59.8 64.9 68.3
7.5 kW 51.8 57.1 59.4 64.7 67.6 72.8 76.1 81.3
10 kW 63.1 70.1 70.7 77.7 78.9 85.9 87.4 94.3
15 kW - - - - - - 93.3 103.7 101.5 111.9 110.0 120.4
20 kW - - - - - - - - - - - - 124.1 137.9 132.5 146.4
NOTE - All units have a minimum Short Circuit Current Rating (SCCR) of 5000 amps.
NOTE - Extremes of operating range are plus and minus 10% of line voltage.
1
HACR type breaker or fuse.
2
3
A separate compressor circuit is required.
