Lennox MCA018S4S-1P

17
Applicationarea-ft.² 130-195 170-250(115V)
160-240(208/230V)
250-355 310-460
Design Pressure
PSIG 550/340 550/340 550/340 550/340
Shipping
Data
Net/Shippingweight(lbs.)(115V) --- 63 / 68 --- ---
(208/230V) 54 / 59 55 / 60 66 / 73 89 / 96
ELECTRICAL DATA
Electrical Characteristics - 60 Hz - 1 Phase
208/230V 115V 208/230V 208/230V 208/230V
1
MaximumOvercurrentProtection(amps) 15 20 15 20 25
2
Minimumcircuitampacity 10 15 11 15 18
CompressorRatedloadamps 6.2 5.05 6.8 9.0 12.0
Outdoor Fan Motor
Ratedloadamps 0.39 0.39 0.39 0.39 0.60
Output-W 58 58 58 58 115
NOTE-Extremesofoperatingrangeareplusandminus10%oflinevoltage.
1
HACRtypecircuitbreakerorfuse.
2
RefertoNationalorCanadianElectricalCodemanualtodeterminewire,fuseanddisconnectsizerequirements.
8.3. Cooling Capacity
8.3.1. - 009 (208/230V)
Outdoor
Temperature - °F
(Dry Bulb)
Indoor Temperature - °F (Dry Bulb / Wet Bulb)
65°F / 54°F 70°F / 59°F 75°F / 63°F 80°F / 67°F
Total
mBtuh
Sensible
mBtuh
Total
mBtuh
Sensible
mBtuh
Total
mBtuh
Sensible
mBtuh
Total
mBtuh
Sensible
mBtuh
–13 6.80 4.84 7.04 4.98 7.61 5.41 8.05 5.67
–5 7.35 5.26 7.70 5.54 8.31 5.95 8.75 6.24
–4 7.45 5.45 7.90 5.75 8.48 6.20 8.93 6.47
0 7.69 5.40 8.05 5.65 8.84 6.21 9.20 6.45
5 7.96 5.70 8.44 6.12 9.11 6.53 9.59 6.86
15 8.56 6.27 9.18 6.79 9.96 7.29 10.37 7.60
25 9.08 6.18 9.57 6.45 10.33 7.03 10.87 7.33
35 9.45 6.51 9.89 6.79 10.61 7.32 11.17 7.72
45 10.45 7.13 10.89 7.46 11.82 8.07 12.44 8.45
55 10.41 7.58 10.97 7.98 11.97 8.71 12.47 9.03
65 10.45 7.61 11.01 8.02 11.89 8.66 12.51 9.12
75 10.61 7.44 11.11 7.79 11.86 8.32 12.55 8.80
85 9.92 7.06 10.39 7.35 11.22 7.98 11.81 8.32
95 9.24 6.81 9.79 7.21 10.45 7.70 11.06 8.27
105 8.69 6.78 9.16 7.14 9.89 7.71 10.40 8.12
110 8.14 6.92 8.63 7.34 9.22 7.83 9.75 8.29
115 7.37 6.56 7.81 6.95 8.43 7.50 8.87 7.90
122 6.59 6.07 6.99 6.43 7.58 6.98 7.90 7.27
