Lennox MERIT ML180DFE

Page 33
BLOWER DATA
TABLE 13
Allowable Heating Speeds
Model Number Red Yellow Blue Brown Black
ML180DF045E36A Not Allowed
Allowed
Factory Setting
Allowed
Not Allowed
ML180DF070E36B Not Allowed
ML180DF090E48B
Allowed
ML180DF110E60C Not Allowed
TABLE 14
Allowable Circulation Speeds
Model Number-
ww
Red Yellow Blue Brown Black
All Models Factory Setting Not Allowed Not Allowed Not Allowed Not Allowed
ML180DF045E36A PERFORMANCE (Less Filter)
External
Static
Pressure
in. w.g.
Air Volume / Watts at Various Blower Speeds
High
(Black)
Medium-High
(Brown)
Medium
(Blue)
Medium-Low
(Yellow)
Low
(Red)
cfm Watts cfm Watts cfm Watts cfm Watts cfm Watts
0.00 1384 268 1164 170 970 111 942 86 867 75
0.10 1347 278 1137 179 947 120 880 94 787 76
0.20 1310 288 1110 188 924 129 818 102 707 77
0.30 1278 301 1066 198 878 135 771 109 645 84
0.40 1259 312 1027 204 831 143 713 115 587 89
0.50 1210 323 995 214 785 149 669 121 530 95
0.60 1183 330 941 220 742 156 615 127 478 100
0.70 1155 338 902 228 702 164 570 134 430 105
0.80 1085 333 873 236 654 170 522 139 384 110
0.90 992 313 831 244 615 176 478 145 - -
1.00 879 286 796 250 574 182 437 150 - -
