LENNOX HEARTH PRODUCTS • MERIT PLUS
®
DIRECT VENT GAS FIREPLACES (MPDP35/40) • CARE AND OPERATION INSTRUCTIONS
OPTIONAL ACCESSORIES
REQUIRED ACCESSORIES
Product Reference Information
Cat.
No.
Model
Ship.
Wt.
Ship.
Volume
H8568 MPDP35IN (NG)
113 lb. 15.8 cu. ft.
H8569 MPDP35IP (LP)
H8570 MPDP40IN (NG)
147 lb. 20.2 cu. ft.
H8571 MPDP40IP (LP)
The brickaded panel liner kits include ceramic
panels of the side walls, the rear and the baffle
of the firebox. The panels have brick-like fea-
tures in relief.
One of the following kits must be installed
for safe operation of this appliance.
Firebox Liner Kits
Cat. No. Model Description
H8572 BLKBP-
MPDP35
Black Porcelain,
MPDP35
H8573 BLKBP-
MPDP40
Black Porcelain,
MPDP40
H0913 MBLK-35 Brickaded, MPDP35
H0914 MBLK-40 Brickaded, MPDP40
These barrier screen kits create a barrier to
prevent direct contact with the hot glass. The
screen panel affixes directly to the front glass
enclosure panel.
Termination Guard Kits (all models)
Cat. No. Model No. Description
H5820 4.5HTSK Termination Shroud
87L02 SV4.5HGS Termination Guard,
Deluxe
Deluxe Termination
Guard (Fits 94L10)
Termination Guard Kits
The vent termination guards may be used to
cover the vent termination on the exterior of the
home to minimize exposure to the hot surface
of the termination.
Termination Shroud
(Fits H1968)
Barrier Screen Kits
Cat. No. Model Description
H7975 HG35M Barrier Screen, MPDP35
H7976 HG40M Barrier Screen, MPDP40
Touch-Up Paint (Black) Kit
Cat. No. Model Description
90L73 TPK-B Touch-Up Paint, Black
Repair of minor scratches and discoloration of
the appliance painted surfaces may be accom-
plished with the touch-up paint kit.
P
A
I
N
T
Bag of Glowing Embers
Bag of Volcanic Stone
Replacement ember materials or volcanic stone
are available for use with these appliances.
Order kits as part of the periodic maintenance
of the appliance.
Decorative Firebox Accessories
Cat. No. Model
No.
Description
88L53 FGE Bag of Glowing Embers
(1 oz. rockwool)
80L42 FDVS
Bag of Decorative
Volcanic Stone
