25
LENNOX HEARTH PRODUCTS • MERIT PLUS
®
DIRECT VENT GAS FIREPLACES (MPDP35/40) • CARE AND OPERATION INSTRUCTIONS
REPLACEMENT PARTS LIST
Item No. Description
MPDP35 MPDP40
Part No. Qty. Part No. Qty.
1 Hood 97K51 1 97K52 1
2 Radiant Panel Assembly, Upper H8661 1 H8662 1
3 Radiant Panel Assembly, Lower H8665 1 H8666 1
4 Enclosure, Glass Front (Complete) H8584 1 H8586 1
5 Nameplate (Brand) 12L15 1 12L15 1
6 Door Latch Spring H1264 2 H1264 2
7 Catch, Door, Magnetic 69L31 2 69L31 2
8 Log Set (Complete) 24M22 1 24M25 1
9 Burner Assembly H8585 1 H8587 1
10 Grate Assembly H6526 1 H6314 1
11 Orifice, Main Burner - Nat. Gas H3721 1 18L40 1
11 Orifice, Main Burner - LP Gas 99K79 1 21L01 1
12 Bag Of Embers (Rockwool) 88L53 1 88L53 1
13 Bag Of Decorative Volcanic Stone 80L42 1 80L42 1
14 Gas Line Flexible Connector 93L32 1 93L32 1
15 CPI Switch (pilot mode) 27K30 1 27K30 1
16 Forced Air Blower, FBK-100 80L84 1 80L84 1
WARNING
Failure to position the parts in
accordance with these diagrams
or failure to use only parts specifi-
cally approved with this appliance
may result in property damage or
personal injury.
AVERTISSEMENT
Risque de dommages ou de
blessures si les pièces ne sont
pas installées conformément à
ces schémas et ou si des pièces
autres que celles spécifiquement
approuvées avec cet appareil sont
utilisées.
Contact an Lennox Hearth Products dealer to
obtain any of these parts. Never use substitute
materials. Use of non-approved parts can
result in poor performance and safety hazards.
GAS CONTROLS — SIT ELECTRONIC
Item No. Description
Natural Gas Propane Gas
Part No Qty Part No Qty
17 Gas Valve H7270 1 H7271 1
18 Pilot Assembly H7268 1 H7269 1
19 DFC Ignition Board H7272 1 H7272 1
20 DFC Wire Harness H7273 1 H7273 1
21 Receiver Kit H7277 1 H7277 1
22 Receiver Cable Harness H7276 1 H7276 1
23 Fan Control Module H7274 1 H7274 1
24 Transmitter Kit H7275 1 H7275 1
25 Ground Wire H7278 1 H7278 1
To Next Page
