Table 4. 13HPX-018
Target *Add
Subcooling charge
INDOOR MATCHUPS Heat Cool
(+5OF) (+1OF) Ib oz
CBX26UH-018 11 9 0 3
CBX32MV-O 18/024-230 12 12 O O
CBX32MV-024/030-230 12 19 1 1
Table 5. 13HPX-024
Target *Add
Subcooling charge
INDOOR MATCHUPS Heat Cool
(+5OF) (+1OF) Ib oz
CBX26UH-024 20 16 1 O
CB3OU-31 14 15 1 5
CBX32M-030 14 15 1 5
CBX32MV-O 18/024 14 15 O 9
CBX32MV-024/030 14 15 1 5
CH33-25B 14 15 O O
CH33-36A 14 15 O 8
CH33-36B 14 15 O O
CH33-36C 14 15 O 14
CR33-30/36 20 16 1 O
CX34-25 14 15 O 9
CX34-31 14 15 1 5
CX34-36 14 15 O 4
Table 6. 13HPX-030
Target *Add
Subcooling charge
INDOOR MATCHUPS Heat Cool
(+5OF) (+1OF) Ib oz
CBX26UH-030 19 6 1 7
CBX26UH-036 25 4 O 11
CBX27UH-030-230 15 4 O 11
CBX27UH-036-230 15 4 O 11
CBX32M-030 -036, -042 15 4 O 11
CBX32MV-024/030, -036 15 4 O 11
CH33-25B 15 4 O O
CH33-31B 15 4 O 11
CH33-36A 15 4 O 8
CH33-36B 15 4 O O
CH33-36C 15 4 O 11
CH33-42 15 4 O 11
CR33-30/36 20 4 O 11
CX34-25, -31 15 4 O 11
CX34-36 28 3 O O
CX34-38 SN# 6007 and after 4 4 O 11
CX34-38 before SN# 6007 20 4 O 11
CX34-42 28 3 O O
Table 7. 13HPX-036
Target
Subcooling
INDOOR MATCHUPS Heat Cool
(+5°F) (+I°F)
CBX26UH-036 14 10
CBX27UH-036-230 10 5
CBX27UH-042-230 10 10
CBX32M-036, -042 10 5
CBX32MV-036-230 10 5
CH33-31A, -31B 10 5
CH33-36B 10 5
CH33-36C 10 5
CH33-42 10 5
CH33-44/48B 10
C H33-48C 10 5
*Amount of charge required in additional to charge shown
plate. (Remember to consider lineset length difference.)
*Add
charge
Ib oz
2 7
2 7
2 13
2 7
2 7
2 8
0 0
0 5
2 8
5 2 10
2 10
on unit name-
Target *Add
Subcooling charge
INDOOR MATCHUPS Heat Cool
(+5OF) (+1OF) Ib oz
CR33-30/36 25 5 0 6
CR33-48 25 5 2 8
CR33-50/60 10 5 2 10
CX34-36B 10 5 0 1
CX34-38 SN# 6007 and after 5 5 2 7
CX34-38 before SN# 6007 10 5 2 7
CX34-42B 10 5 0 1
CX34-44/48B 10 5 2 7
Table 8. 13HPX-042
Target *Add
Subcooling charge
INDOOR MATCHUPS Heat Cool
(+5OF) (+1OF) Ib oz
CBX26UH-042 26 5 1 1
CBX26UH-048 10 12 4 5
CBX27UH-042-230 10 6 4 5
CBX27UH-048-230 10 6 4 5
CBX32M-036, -042 15 5 O O
CBX32MV-036 15 5 O O
CBX32MV-048-230 10 6 4 5
CH33-43C, -48C 10 6 1 1
CH33-49C, -50/60C 10 6 4 5
CH33-6OD 10 6 2 6
CR33-48 32 5 O 5
CR33-50/60 32 9 2 6
CR33-60 32 9 2 6
CX34-43C 10 6 1 1
CX34-49 10 6 3 7
CX34-50/60C 10 6 1 1
Table 9. 13HPX-048
Target *Add
Subcooling charge
INDOOR MATCHUPS Heat Cool
(+5OF) (+1OF) Ib oz
CBX26UH-048 11 11 1 7
CBX26UH-060 24 18 2 7
CBX27UH-048-230 11 11 1 3
CBX27UH-060-230 24 18 2 7
CBX32M-048 11 11 1 3
CBX32M-060 11 11 1 3
CBX32MV-048 11 11 1 3
CBX32MV-060-230 11 11 1 3
CH33-43C 18 7 O O
CH33-49C, -50/60C 11 11 1 3
CH33-6OD 11 11 O 9
CH33-62D 11 11 1 10
CR33-50/60 25 7 O 9
CR33-60 25 7 O 9
CX34-49 11 11 1 1
CX34-6OD 11 11 O 9
Table 10. 13HPX-060
Target *Add
Subcooling charge
INDOOR MATCHUPS Heat Cool
(+5OF) (+1OF) Ib oz
CBX26UH-060 8 11 1 7
CBX27UH-060-230 10 9 O 13
CBX32MV-060 10 9 O O
CBX32MV-068 10 9 O 9
CH33-6OD 10 9 O O
CH33-62D 10 9 O 11
CX34-62D 10 9 O 6
Page15
