Table 5. MLB and MPC Multi-Zone System Combinations
NOTE - For multi-zone systems, the total capacity of all indoor units must be 66% to 133% of the outdoor unit capacity.
Outdoor Unit
Model No.
Number
of
Zones
Indoor Unit
Capacity
Nominal Cooling Capacity at Rated
System Capacity (Btuh)
Nominal Heating Capacity at Rated
System Capacity (Btuh)
#1 #2 #3 #4 #5 #1 #2 #3 #4 #5 #1 #2 #3 #4 #5
MLB and
MPC048S4M
2
24K 9K - - - - - - - - - 24,000 9,000 - - - - - - - - - 25,100 9,400 - - - - - - - - -
30K 9K - - - - - - - - - 29,000 8,000 - - - - - - - - - 30,400 9,100 - - - - - - - - -
36K 9K - - - - - - - - - 33,000 8,000 - - - - - - - - - 34,500 8,600 - - - - - - - - -
24K 12K - - - - - - - - - 23,000 11,000 - - - - - - - - - 24,800 12,400 - - - - - - - - -
30K 12K - - - - - - - - - 28,000 11,000 - - - - - - - - - 29,600 11,900 - - - - - - - - -
36K 12K - - - - - - - - - 31,000 10,000 - - - - - - - - - 33,200 11,100 - - - - - - - - -
18K 18K - - - - - - - - - 17,000 17,000 - - - - - - - - - 18,600 18,600 - - - - - - - - -
24K 18K - - - - - - - - - 22,000 17,000 - - - - - - - - - 23,700 17,800 - - - - - - - - -
30K 18K - - - - - - - - - 26,000 15,000 - - - - - - - - - 27,600 16,600 - - - - - - - - -
36K 18K - - - - - - - - - 28,000 14,000 - - - - - - - - - 30,000 15,000 - - - - - - - - -
24K 24K - - - - - - - - - 21,000 21,000 - - - - - - - - - 22,000 22,000 - - - - - - - - -
30K 24K - - - - - - - - - 23,000 18,000 - - - - - - - - - 25,000 20,000 - - - - - - - - -
36K 24K - - - - - - - - - 23,000 15,000 - - - - - - - - - 26,000 17,300 - - - - - - - - -
30K 30K - - - - - - - - - 19,000 19,000 - - - - - - - - - 21,700 21,700 - - - - - - - - -
3
24K 6K 6K - - - - - - 24,000 6,000 6,000 - - - - - - 25,500 6,400 6,400 - - - - - -
30K 6K 6K - - - - - - 29,000 6,000 6,000 - - - - - - 30,100 6,100 6,100 - - - - - -
36K 6K 6K - - - - - - 33,000 5,000 5,000 - - - - - - 34,300 5,800 5,800 - - - - - -
24K 9K 6K - - - - - - 23,000 9,000 6,000 - - - - - - 24,800 9,300 6,200 - - - - - -
30K 9K 6K - - - - - - 28,000 8,000 6,000 - - - - - - 29,300 8,800 5,900 - - - - - -
36K 9K 6K - - - - - - 32,000 8,000 5,000 - - - - - - 33,500 8,400 5,600 - - - - - -
18K 12K 6K - - - - - - 18,000 12,000 6,000 - - - - - - 19,100 12,800 6,400 - - - - - -
24K 12K 6K - - - - - - 23,000 11,000 6,000 - - - - - - 24,100 12,100 6,100 - - - - - -
30K 12K 6K - - - - - - 27,000 11,000 5,000 - - - - - - 28,600 11,500 5,800 - - - - - -
36K 12K 6K - - - - - - 31,000 10,000 5,000 - - - - - - 32,700 10,900 5,500 - - - - - -
18K 18K 6K - - - - - - 17,000 17,000 6,000 - - - - - - 18,100 18,100 6,100 - - - - - -
24K 18K 6K - - - - - - 22,000 16,000 5,000 - - - - - - 22,900 17,200 5,800 - - - - - -
30K 18K 6K - - - - - - 26,000 15,000 5,000 - - - - - - 27,300 16,400 5,500 - - - - - -
36K 18K 6K - - - - - - 29,000 14,000 5,000 - - - - - - 31,400 15,700 5,300 - - - - - -
24K 24K 6K - - - - - - 20,000 20,000 5,000 - - - - - - 21,800 21,800 5,500 - - - - - -
30K 24K 6K - - - - - - 24,000 19,000 5,000 - - - - - - 26,200 21,000 5,300 - - - - - -
18K 9K 9K - - - - - - 18,000 9,000 9,000 - - - - - - 19,100 9,600 9,600 - - - - - -
24K 9K 9K - - - - - - 23,000 9,000 9,000 - - - - - - 24,100 9,100 9,100 - - - - - -
30K 9K 9K - - - - - - 27,000 8,000 8,000 - - - - - - 28,600 8,600 8,600 - - - - - -
36K 9K 9K - - - - - - 31,000 8,000 8,000 - - - - - - 32,700 8,200 8,200 - - - - - -
12K 12K 9K - - - - - - 12,000 12,000 9,000 - - - - - - 13,200 13,200 9,900 - - - - - -
18K 12K 9K - - - - - - 18,000 12,000 9,000 - - - - - - 18,600 12,400 9,300 - - - - - -
24K 12K 9K - - - - - - 22,000 11,000 8,000 - - - - - - 23,500 11,800 8,800 - - - - - -
30K 12K 9K - - - - - - 26,000 11,000 8,000 - - - - - - 27,900 11,200 8,400 - - - - - -
36K 12K 9K - - - - - - 30,000 10,000 7,000 - - - - - - 32,100 10,700 8,100 - - - - - -
18K 18K 9K - - - - - - 17,000 17,000 8,000 - - - - - - 17,600 17,600 8,800 - - - - - -
24K 18K 9K - - - - - - 21,000 16,000 8,000 - - - - - - 22,300 16,800 8,400 - - - - - -
30K 18K 9K - - - - - - 25,000 15,000 7,000 - - - - - - 26,700 16,100 8,100 - - - - - -
36K 18K 9K - - - - - - 28,000 14,000 7,000 - - - - - - 30,900 15,500 7,800 - - - - - -
24K 24K 9K - - - - - - 20,000 20,000 7,000 - - - - - - 21,400 21,400 8,100 - - - - - -
30K 24K 9K - - - - - - 23,000 19,000 7,000 - - - - - - 25,700 20,600 7,800 - - - - - -
12K 12K 12K - - - - - - 12,000 12,000 12,000 - - - - - - 12,800 12,800 12,800 - - - - - -
