MLB048S4M / MPC048S4M
Number of Zones and Outdoor Unit Connection Sizes
NOTE - Letter = Indoor Unit Zone Connection on Outdoor Unit
Zone 1 (A) Zone 2 (B) Zone 3 (C) Zone 4 (D) Zone 5 (E)
1/4 in. liq + 1/2 in. gas 1/4 in. liq + 1/2 in. gas 1/4 in. liq + 3/8 in. gas 1/4 in. liq + 3/8 in. gas 1/4 in. liq + 3/8 in. gas
024 009 - - - - - - - - -
030 009 - - - - - - - - -
024 012 - - - - - - - - -
030 012 - - - - - - - - -
018 018 - - - - - - - - -
024 018 - - - - - - - - -
024 024 - - - - - - - - -
030 018 - - - - - - - - -
030 024 - - - - - - - - -
030 030 - - - - - - - - -
024 006 006 - - - - - -
030 006 006 - - - - - -
024 009 006 - - - - - -
030 009 006 - - - - - -
018 012 006 - - - - - -
024 012 006 - - - - - -
030 012 006 - - - - - -
018 018 006 - - - - - -
024 018 006 - - - - - -
030 018 006 - - - - - -
024 024 006 - - - - - -
030 024 006 - - - - - -
018 009 009 - - - - - -
024 009 009 - - - - - -
030 009 009 - - - - - -
012 012 009 - - - - - -
018 012 009 - - - - - -
024 012 009 - - - - - -
030 012 009 - - - - - -
018 018 009 - - - - - -
024 018 009 - - - - - -
030 018 009 - - - - - -
024 024 009 - - - - - -
030 024 009 - - - - - -
012 012 012 - - - - - -
018 012 012 - - - - - -
024 012 012 - - - - - -
030 012 012 - - - - - -
018 018 012 - - - - - -
024 018 012 - - - - - -
030 018 012 - - - - - -
LEGEND:
CLEAR = No adaptors required.
GRAY = 3/8 x 1/2 in. gas pipe adaptor is required for line set connection to outdoor unit (furnished with outdoor unit).
BLACK = 1/4 x 3/8 in. liquid pipe adaptor is required for line set connection to the 048 outdoor unit (furnished with outdoor unit).
1/2 x 5/8 in. gas pipe adaptor is required for line set connection to the 048 outdoor unit (furnished with outdoor unit).
