Outdoor Unit Information
6. Single and Multi-Zone Outdoor Units
NOTE: Outdoor units can only be installed in an unenclosed outdoor environment.
6.1. Model Number Identication
M P C 018 S 4 S - 1 P
Series Type
M = Mini-Split
OUTDOOR SINGLE ZONE HEAT PUMP UNITS - MPC
Cooling E󰀩ciency
S = Standard E󰀩ciency
Major Design Sequence
A = 1st Generation
B = 2nd Generation
C = 3rd Generation
Refrigerant Type
4 = HFC-410A
Refrigerant Circuits
S = Single Circuit
Minor Design Sequence
1 = 1st Revision
Voltage
P = 208/230V-1 phase-60hz
Nominal Cooling Capacity
018 = 1.5 tons
024 = 2 tons
036 = 3 tons
048 = 4 tons
060 = 5 tons
Unit Type
L = Low Ambient Heat Pump
P = Heat Pump
Unit Type
L = Low Ambient Heat Pump
Series Type
M = Mini-Split
Cooling Efciency
S = Standard E󰀩ciency
Major Design Sequence
B = 2nd Generation
Nominal Cooling Capacity
018 = 1.5 tons
024 = 2 tons
036 = 3 ton
048 = 4 ton
Refrigerant Type
4 = R-410A
Refrigerant Circuits
S = Single Circuit
Minor Design Sequence
1 = 1st Revision
Voltage
P = 208/230V-1 phase-60Hz
WARNING
The clean Air Act of 1990 bans the intentional venting of
refrigerant (CFCs, HCFCs, and HFCs) as of July, 1992.
Approved methods of recovery, recycling or reclaiming
must be followed. Fines and/or incarceration may be
levied for non-compliance.
CAUTION
As with any mechanical equipment, contact with sharp
sheet metal edges can result in personal injury. Take
care while handling this equipment and wear gloves and
protective clothing.
M L B 018 S 4 S - 1 P
OUTDOOR SINGLE ZONE HEAT PUMP UNITS - MLB
