MPC SPECIFICATIONS SINGLE ZONE | 5 TON
Nominal Size - Tons 5
Outdoor Unit Model No. MPC060S4S
Ambient Temperature
Operating Range - °F
Cooling 60 - 90
Heating 32 - 86
Sound Data
(dBA)
Cooling/Heating
Hi/Med/Low
50 / 47 / 45
Refrigerant
(R-410A)
Charge furnished
10 lbs. 9 oz.
Maximum line length with furnished charge - ft. 25
Additional charge required per ft. - oz. 0.32
Compressor No. and Type (1) Rotary
Refrigerant oil type VG74
Refrigerant oil charge - oz. 47.3
Connections - in. Liquid/Gas pipe (are) 3/8 / 7/8
Maximum refrigerant pipe length - ft. 213
Max. dierence in level of indoor unit - ft. 98
Outdoor
Fan
(No.) Diameter - in. (2) 22
Total air volume - cfm 4500
rpm 900
Outdoor Coil Number of rows 5
Fins per inch 1.3
Fin type Hydrophilic aluminum
Tube outside diameter - in. 3/8
Tube type Ried copper tubing
Net face area - ft.
2
13.58
Design Pressure PSIG 550 / 340
Shipping
Data
Net/Shipping weight (lbs.) 164 / 190
ELECTRICAL DATA
Electrical Characteristics - 60 Hz - 1 Phase 208/230
1
Maximum Overcurrent Protection (MOCP) amps 50
2
Minimum circuit ampacity (MCA) 39
Outdoor Fan
Motor
Output - W 85
NOTE - Extremes of operating range are plus and minus 10% of line voltage.
1
HACR type circuit breaker or fuse.
2
Refer to National or Canadian Electrical Code manual to determine wire, fuse and disconnect size requirements.
