MLB036S4M / MPC036S4M

Number of Zones and Outdoor Unit Connection Sizes

NOTE - Letter = Indoor Unit Zone Connection on Outdoor Unit

Zone 1 (A) Zone 2 (B) Zone 3 (C) Zone 4 (D)

1/4 in. liq + 1/2 in. gas 1/4 in. liq + 3/8 in. gas 1/4 in. liq + 3/8 in. gas 1/4 in. liq + 3/8 in. gas

018 006 - - - - - -

024 006 - - - - - -

018 009 - - - - - -

024 009 - - - - - -

012 012 - - - - - -

018 012 - - - - - -

024 012 - - - - - -

018 018 - - - - - -

024 018 - - - - - -

024 ¹ 024 - - - - - -

012 006 006 - - -

018 006 006 - - -

024 006 006 - - -

012 009 006 - - -

018 009 006 - - -

024 009 006 - - -

012 012 006 - - -

018 012 006 - - -

024 012 006 - - -

018 018 006 - - -

024 018 006 - - -

009 009 009 - - -

012 009 009 - - -

018 009 009 - - -

024 009 009 - - -

012 012 009 - - -

018 012 009 - - -

024 012 009 - - -

018 018 009 - - -

012 012 012 - - -

018 012 012 - - -

024 012 012 - - -

018 018 012 - - -

006 006 006 006

009 006 006 006

012 006 006 006

018 006 006 006

024 006 006 006

009 009 006 006

LEGEND:

CLEAR = No adaptors required.

GRAY = 3/8 x 1/2 in. gas pipe adaptor is required for line set connection to outdoor unit (furnished with outdoor unit).

BLACK = 1/4 x 3/8 in. liquid pipe adaptor is required for line set connection to the 036 outdoor unit (furnished with outdoor unit).

1/2 x 5/8 in. gas pipe adaptor is required for line set connection to the 036 outdoor unit (furnished with outdoor unit).

1/4 x 3/8 in. liquid pipe adaptor is required for line set connection to the 036 outdoor unit (furnished with outdoor unit).

3/8 x 5/8 in. gas pipe adaptor is required for line set connection to the 036 outdoor unit (not furnished).
