SPECIFICATIONS - CASSETTE INDOOR UNITS - M22A009-018
Model No. M22A009S4-1P M22A012S4-1P M22A018S4-1P
Nominal Tons 0.75 1 1.5
Power Supply - 60 hz - 1 phase 208/230V 208/230V 208/230V
Rated load amps 0.9 1.0 1.5
Output (W) 46 46 46
Air Volume - cfm (High/Medium/Low) 380/320/260 400/340/280 420/350/290
Sound Data (dBA) - Low/Medium/High 37/39/41 35/38/41 41/43/46
Piping Connections - Liquid/Gas - o.d. - fl are - in. 1/4 / 3/8 1/4 / 1/2 1/4 / 1/2
Drain connection o.d. - in. 1 1 1
Net/Shipping weights - lbs. Body 36 / 42 36 / 42 40 / 47
REQUIRED COMPONENTS - ORDERED SEPARATELY
Cassette Panel 13X04 (M0STAT62Q-1) 13X04 (M0STAT62Q-1) 13X04 (M0STAT62Q-1)
Net/Shipping weights - lbs. 6 / 10 6 / 10 6 / 10
