Lennox Mini-Split Service Manual / Page 248

EXV Check

Disconnect the connectors.

Resistance to EXV Coil

Color of lead wire Normal Value

Red- Blue

About 50Ω

Red - Yellow

Brown-Orange

Brown-White
