38
NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
LENNOX HEARTH PRODUCTS • MERIT PLUS
®
DIRECT VENT GAS FIREPLACES (MPD33/35/40/45) • INSTALLATION INSTRUCTIONS
Millivolt SIT Systems
Propane Gas to Natural Gas
Conversion Kits
Models Catalog No.
MPD33 H2010
MPD35 H2012
MPD40 H2014
MPD45 H2016
Millivolt SIT Systems
Natural Gas To Propane Gas
Conversion Kits
Models Catalog No.
MPD33 H2009
MPD35 H2011
MPD40 H2013
MPD45 H2015
Electronic SIT Systems
Propane Gas To Natural Gas
Conversion Kits
Models Catalog No.
MPD33 H8631
MPD35 H8633
MPD40 H8635
MPD45 H8637
In Canada:
THE CONVERSION SHALL BE CARRIED
OUT BY A MANUFACTURER’S
AUTHORIZED REPRESENTATIVE,
IN ACCORDANCE WITH THE
REQUIREMENTS OF THE
MANUFACTURER, PROVINCIAL OR
TERRITORIAL AUTHORITIES HAVING
JURISDICTION AND IN ACCORDANCE
WITH THE REQUIREMENTS OF THE
CAN/CGA-B149.1 OR CAN/CGA-B149.2
INSTALLATION CODES.
LA CONVERSION DEVRA ÊTRE
EFFECTUÉE CONFORMÉMENT AUX
RECOMMANDATIONS DES AUTORITÉS
PROVINCIALES AYANT JURIDICTION
ET CONFORMÉMENT AUX EXIGENCES
DU CODE D'INSTALLATION CAN/
CSA-B149.1.
Gas conversion kits are available to adapt
your appliance from the use of one type of
gas to the use of another. These kits contain
all the necessary components needed to
complete the task including labeling that
must be affi xed to ensure safe operation.
GAS CONVERSION KITS
INSTALLATION INSTRUCTIONS
Step 1. TURN OFF THE GAS SUPPLY TO THE
APPLIANCE and disconnect power supply at
the circuit breaker. Ensure appliance is cold.
CAUTION: THE GAS SUPPLY SHALL BE
SHUT OFF PRIOR TO DISCONNECTING
THE ELECTRICAL POWER, BEFORE
PROCEEDING WITH THE CONVERSION.
ATTENTION: AVANT D’EFFECTUER
LA CONVERSION, COUPEZ D’ABORD
L’ALIMENTATION EN GAZ, ENSUITE,
COUPEZ L’ALIMENTATION ÉLECTRIQUE.
Step 2. Open the lower control compartment
door (see Figure 48 on Page 27) by pushing
on the right top corner of the door (the door
is hinged at the bottom).
[Optional] Remove the control compartment
door by sliding the hinge pin, located at the
door’s left side, to the right until it disengages
from the left corner post hole. Pull the
control compartment door diagonally to the
left, away from the fi replace.
Step 3. Remove the front glass door/frame
from the appliance (see Page 32).
Electronic SIT Systems
Natural Gas To Propane Gas
Conversion Kits
Models Catalog No.
MPD33 H8632
MPD35 H8634
MPD40 H8636
MPD45 H8638
WARNING
This conversion kit shall be installed by a qualifi ed service agency in
accordance with the manufacturer’s instructions and all applicable codes
and requirements of the authority having jurisdiction. If the information in
these instruction is not followed exactly, a fi re, explosion or production of
carbon monoxide may result causing property damage, personal injury
or loss of life. The qualifi ed service agency is responsible for the proper
installation of this kit. The installation is not proper and complete until the
operation of the converted appliance is checked as specifi ed in the manu-
facturer’s instructions supplied with the kit.The qualifi ed service agency
performing this installation assumes responsibility for this conversion.
AVERTISSEMENT
Cette trousse de conversion doit être installée par un technicien agréé,
selon les instructions du fabricant et selon toutes les exigences et tous les
codes pertinents de l’autorité compétente. Assurez-vous de bien suivre
les instructions dans cette notice pour réduire au minimum le risque
d’incendie, d’explosion ou la production de monoxyde de carbone pouvant
causer des dommages matériels, des blessures ou la mort. Le tecnicien
agréé est responsable de l’installation de cette trousse. L’installation n’est
pas adéquate ni complète tant que le bon fonctionnement de l’appareil
converti n’a pas été vérifi é selon les instructions du fabricant fournies avec
la trousse. Le fournisseur de service qualifi é ayant réalisé l'installation
assume les responsabilités liées à la conversion.
Kit part numbers are listed here and the
following steps detail the conversion
procedure. Refer to the instructions provided
with the conversion kit when performing any
gas conversion.
To Next Page
