20
NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
LENNOX HEARTH PRODUCTS • MERIT PLUS
®
DIRECT VENT GAS FIREPLACES (MPD33/35/40/45) • CARE AND OPERATION INSTRUCTIONS
These louvers are designed to replace the
standard radiant panels that are provided
with the appliance.
ACCESSORY COMPONENTS (continued)
stiKrevuoLdelbmessA
ledoM
.oN
.oNgolataC
.oNledoM
Black Louvers
MPD33
MPD35
MPD40
MPD45
H8839
LVR33C-2
88L24
LVR35C-2
88L25
LVR40C-2
88L26
LVR45C-2
These screen panels can be installed on the
glass enclosure panel to provided protection
from the hot glass surface. The screen panel
kits cannot be used in conjunction with either
of the arch door kits or door frame kits.
stiKlenaPneercS
.oNledoM
.oNgolataC
.oNledoM
MPD33
40L89
33GH
MPD35
84M62
M53GH
MPD40
94M62
M04GH
MPD45
05M62
M54GH
Termination Guard Kits (all models)
Cat. No. Model No. Description
H5820 4.5HTSK Termination Shroud
87L02 SV4.5HGS Termination Guard,
Deluxe
17M52 SV4.5HGS-1 Termination Guard,
Square
Square Termination
Guard (Fits 94L10)
Deluxe Termination
Guard (Fits 94L10)
Termination Guard Kits
The vent termination guards may be used to
cover the vent termination on the exterior of
the home to minimize exposure to the hot
surface of the termination.
Termination Shroud
(Fits H1968)
The fi rebox liner kits include ceramic panels
of the side walls, the rear and the baffl e of the
fi rebox. The panels have brick-like features
in relief.
Firebox Liner Kits
Models Catalog No. Model No.
MPDT33 H0912 MBLK33T
MPDR33 H8614 BLKC-MP33R
MPD35 H8595 BLKC-MP35
MPD40 H8596 BLKC-MP40
MPD45 H0915 MBLK45
