Lennox SCH120 - Circuit 1 SG;SC 240 Reheat Curves; Circuit 2 SG;SC 240 Reheat Curves

Page 39
SGH/SCH036, 060, 120, 240
Suction Pressure (psig)
115°
105°
95°
85°
75°
65°
60
70
80
90
100
110
120
100 110 120 130 140 150 160
Circuit 1 - SG/SC 240 - Reheat - 580976-01
Outdoor Temperature (°F)
170
Suction Pressure (psig)
115°
105°
95°
85°
75°
65°
Circuit 2 - SG/SC 240 - Reheat - 580976-01
Outdoor Temperature (°F)
60
70
80
90
100
110
120
100 110 120 130 140 150 160 170
