Page 3
SGH/SCH036, 060, 120, 240
SG / SC 120 Dimensions - SG Heat Section Shown
1−1/2
(38)
CONDENSATE
DRAIN
FRONT VIEW
SIDE VIEW
LIFTING HOLES
(For Rigging Front and Back)
90−1/4
(2292)
92−1/8
(2340)
31−3/16
(792)
3−1/2
(89)
GAS
SUPPLY
FORKLIFT
SLOTS
51−3/8
(1305)
47−7/8
(1216)
77−5/16
(1964)
86−7/16
(2196)
5−3/8
(137)
5−1/4
(133)
BOTTOM OUTDOOR
AIR INTAKE
CIRCUIT
BREAKER
COVER
FLUE
OUTLET
CONDENSER
FANS AND
GUARDS (2)
OUTDOOR AIR HOOD
(Factory Installed Option)
TOP VIEW
40 (1016)
15 (381)
20 (508)
28 (711)
18 (457)
12−3/8
(314)
12−3/8
(314)
4−1/4
(108)
4
(102)
SUPPLY AIR
OPENING
RETURN AIR
OPENINGS
4
(102)
BOTTOM POWER/GAS
ENTRY 5 x 8 INCHES
(127 x 203 mm)
BOTTOM OUTDOOR
AIR INTAKE
