Lennox SCH120 User Manual

61−15/16
(1573)
CONDENSER
FANS AND GUARDS (6)
FRONT VIEW
TOP VIEW
SIDE VIEW
FORKLIFT
SLOTS
90−1/4
(2292)
30−7/8
(784)
120−1/4
(3054)
145−1/4
(3689)
LIFTING HOLES
(For Rigging
Front and Back)
BOTTOM SUPPLY
AIR OPENINGS
BOTTOM RETURN
AIR OPENING
4−1/4
(108)
4−1/2
(114)
28
(711)
28
(711)
4 (102)
9 (229)
20 (508)
20 (508)
18 (457)
OUTDOOR AIR HOOD
(Factory Installed Option)
CONDENSATE
DRAIN
5−3/8
(137)
3−1/4
(83)
GAS
SUPPLY
CIRCUIT
BREAKER
COVER
115V OUTLET
(Factory*Installed Inside Unit;
Field Wiring Required)
9*1/4
(235)
1*3/4
(45)
FORKLIFT
SLOTS
65−3/16
(1656)
BOTTOM POWER/GAS
ENTRY 5 x 8 INCHES
(127 x 203 mm)
FLUE
OUTLET
91−1/2
(2324)
15 (381)
60−1/2 (1537)
17−3/8
(441)
17−3/8
(441)
Page 4
507964-01 9/2019
SG / SC 240 Dimensions - SG Heat Section Shown
