SGH/SCH036, 060, 120, 240
SG 240 Parts Arrangement
COMBUSTION AIR
INDUCERS (2)
EVAPORATOR
COIL
BLOWER
MOTOR
CONDENSER
FANS (6)
CONDENSER
COILS
COMPRESSORS (4)
BURNERS
GAS VALVES (2)
CONDENSATE
DRAIN
FILTERS
(TWELVE
20 X 20 X 2”)
ECONOMIZER
DAMPERS
(OPTIONAL)
UNIT
CONTROLLER
SUPPLY AIR VFD
FILTER
DRIERS
REHEAT
COIL
SC 240 Parts Arrangement
BLOWER
MOTOR
FILTERS (TWELVE
20 X 20 X 2”)
ELECTRIC HEAT
(Optional)
EVAPORATOR
COIL
CONDENSER
FANS (6)
CONDENSER
COILS
COMPRESSORS (4)
CONDENSATE
DRAIN
ECONOMIZER
DAMPERS
(OPTIONAL)
UNIT
CONTROLLER
FILTER
DRIERS
SUPPLY AIR VFD
REHEAT
COIL
