Lennox SCH240

Page 37
SGH/SCH036, 060, 120, 240
Outdoor Temperature (°F)
Suction Pressure (psig)
115°
105°
95°
85°
75°
65°
60
70
80
90
100
110
120
100 110 120 130 140 150 160
Circuit 1 - SG/SC 240 - No Reheat - 580974-01
170
Suction Pressure (psig)
115°
105°
95°
85°
75°
65°
Circuit 2 - SG/SC 240 - No Reheat - 580974-01
Outdoor Temperature (°F)
60
70
80
90
100
110
120
100 110 120 130 140 150 160 170
