Lennox SCH240

Page 40
507964-01 9/2019
Suction Pressure (psig)
115°
105°
95°
85°
75°
65°
60
70
80
90
100
110
120
Circuit 3 - SG/SC 240 - Reheat - 580976-01
Outdoor Temperature (°F)
100 110 120 130 140 150 160 170
Suction Pressure (psig)
115°
105°
95°
85°
75°
65°
70
80
90
100
110
120
110 120 130 140 150 160
Circuit 4 - SG/SC 240 - Reheat - 580976-01
Outdoor Temperature (°F)
170100
60
