Lennox SCH240

Page 5
SGH/SCH036, 060, 120, 240
SG 036 & 060 Parts Arrangement
COMBUSTION
AIR INDUCER
EVAPORATOR
COIL
CONDENSER FANS
CONDENSER
COIL
COMPRESSOR
GAS VALVE
BLOWER
CONDENSATE
DRAIN
FILTERS
(FOUR - 16 X 20 X 2”)
ECONOMIZER
DAMPERS
(OPTIONAL)
BURNERS
FILTER DRIER
UNIT
CONTROLLER
REHEAT COIL
SC 036 & 060 Parts Arrangement
EVAPORATOR
COIL
CONDENSER FANS
CONDENSER COIL
COMPRESSOR
ELECTRIC
HEAT
(OPTIONAL)
BLOWER
CONDENSATE
DRAIN
FILTERS (FOUR
16 X 20 X 2”)
ECONOMIZER
DAMPERS
(OPTIONAL)
FILTER DRIER
UNIT
CONTROLLER
REHEAT COIL
