BLOWER DATA
SLO185BF79/105V42 BLOWER PERFORMANCE
0 through 0.50 in. w.g. External Static Pressure Range
“ADJUST”
Jumper
Setting
Jumper Speed Positions
“HEAT” Speed
“COOL” Speed
.65 High Fire .50 Low Fire
BDABCD
cfm cfm cfm cfm cfm cfm
+ N/A N/A 1500 1400 1200 950
NORM 1450 1200 1400 1200 1000 800
– N/A N/A 1200 1050 860 650
NOTE − Continuous Fan air volume is 50% of COOL speed.
SLO185BF124/141V60 BLOWER PERFORMANCE
0 through 0.50 in. w.g. External Static Pressure Range
“ADJUST”
Jumper
Setting
Jumper Speed Positions
“HEAT” Speed
“COOL” Speed
.85 High Fire .75 Low Fire
BCABCD
cfm cfm cfm cfm cfm cfm
+ N/A N/A 2100 2000 1800 1350
NORM 1730 1550 2000 1800 1600 1200
– N/A N/A 1650 1500 1350 950
NOTE − Continuous Fan air volume is 50% of COOL speed.
SLO185BR124/141V60 BLOWER PERFORMANCE
0 through 0.50 in. w.g. External Static Pressure Range
“ADJUST”
Jumper
Setting
Jumper Speed Positions
“HEAT” Speed
“COOL” Speed
.85 High Fire .75 Low Fire
BDABCD
cfm cfm cfm cfm cfm cfm
+ N/A N/A 2100 2000 1800 1350
NORM 1730 1450 2000 1800 1600 1200
– N/A N/A 1650 1500 1350 950
NOTE − Continuous Fan air volume is 50% of COOL speed.
SLO185BR79/105V42 BLOWER PERFORMANCE
0 through 0.50 in. w.g. External Static Pressure Range
“ADJUST”
Jumper
Setting
Jumper Speed Positions
“HEAT” Speed
“COOL” Speed
.65 High Fire .50 Low Fire
ADABCD
cfm cfm cfm cfm cfm cfm
+ N/A N/A 1500 1400 1200 950
NORM 1550 1200 1400 1200 1000 800
– N/A N/A 1200 1050 860 650
NOTE − Continuous Fan air volume is 50% of COOL speed.
Table 7
