Dimensions - inches (mm) Upow Position Shown
FRONT VIEW SIDE VIEW
TOP VIEW
SUCTION
LINE
LIQUID
LINE
D
1-1/4 (32)
CONDENSATE DRAIN
B
LINE VOLTAGE INLETS
(Top and Either Side)
LOW VOLTAGE INLETS
(Top and Either Side)
C
FILTER ACCESS
AIR FLOW
A
RETURN AIR
E
SUPPLY AIR
1-5/8
(41)
3
(76)
10-1/4 (260)
3/4 (19)
F G
RETURN AIR
Dimension 018-030 036-054
in. mm in. mm
A 45-3/4 1162 53-3/4 1365
B 19-3/4 502 22 560
C 17-7/8 454 19-1/2 495
D 21-5/8 549 24 610
E 13-3/4 349 19-1/2 495
F 18-1/2 470 20-3/8 518
G 20-3/4 527 22-3/4 578
