Lennox Wired Controller User Manual

4
2. Remove the cover from the wall plate using a at-head screwdriver. See gure 2.
3. Mount the wall plate as appropriate for your application. See gure 3.
NOTE – Provide for future maintenance by allowing enough slack in the wiring to
allow the controller to be removed from the wall if needed.
Figure 2. Remove cover from wall plate.
Slots
Figure 1. Wiring Connections
Indoor unit
display board
5-conductor wire
5-conductor wire
1. Connect controller to indoor unit main control board by inserting the plug of the
5-conductor cable into the socket provided at the indoor unit
