Figure 3. Mount wall plate
4. Attach the wall plate using the provided screws. See gure 3.
J-box
Back plate
Back plate
Screws
Screw
Screws
Figure 4. Reattach cover to wall plate
5. Reattach the cover to the wallplate. See gure 4.
