Model Number Identification
P 14 XXX
Unit Type
P = Heat Pump Outdoor Unit
Series
Nominal Cooling Capacity
018 = 1.5 tons
024 = 2 tons
030 = 2.5 tons
036 = 3 tons
042 = 3.5 tons
048 = 4 tons
060 = 5 tons
Minor Revision Number
230
Voltage
230 = 208/230V-1ph-60hz
Refrigerant Type
X = HFC-410A
X 2
0
Typical Serial Number Identification
19 09 C
Year Code
08 = 2008
09 = 2009
10 = 2010
Month Code
A = January
B = February
C = March
05716
5 (or 6) Digit Unique Number
Location Code
19 = Saltillo, Mexico
58 = Marshalltown, IA
Specifications
Model Number
Unit Outdoor Fan
Sound Rating Number
(dB)
1
Factory Refrigerant
Charge
2
Number of Blades Diameter - inches.
XP14-018-230-01, -03, -06, -07 71 8 lbs. 4 oz. 3 18
XP14-018-230-08 71 6 lbs. 11 oz. 3 18
XP14-018-230-09 71
6 lbs. 11 oz. or
5 lbs. 11 oz.
3
3 18
1
Tested according to AHRI Standard 270-2008 test conditions.
2
Refrigerant charge sufficient for 15 feet of line set.
3
Later models employed a smaller filter drier resulting in less refrigerant charge required. Verify factory charge from unit nameplate.
Model Number
Unit Outdoor Fan
Sound Rating Number
(dB)
1
Factory Refrigerant
Charge
2
Number of Blades Diameter - inches.
XP14-024-230-01, -03, -06, -07 71 8 lbs. 0 oz. 3 18
XP14-024-230-08 71 6 lbs. 4 oz. 3 18
XP14-024-230-09 71
6 lbs. 4 oz. or
5 lbs. 14 oz.
3
3 18
1
Tested according to AHRI Standard 270-2008 test conditions.
2
Refrigerant charge sufficient for 15 feet of line set.
3
Later models employed a smaller filter drier resulting in less refrigerant charge required. Verify factory charge from unit nameplate.
Model Number
Unit Outdoor Fan
Sound Rating Number
(dB)
1
Factory Refrigerant
Charge
2
Number of Blades Diameter - inches.
XP14-030-230-01 through -07 71 7 lbs. 2 oz. 3 18
XP14-030-230-08 71 6 lbs. 0 oz. 3 18
XP14-030-230-09 71
6 lbs. 0 oz. or
5 lbs. 10 oz.
3
3 18
1
Tested according to AHRI Standard 270-2008 test conditions.
2
Refrigerant charge sufficient for 15 feet of line set.
3
Later models employed a smaller filter drier resulting in less refrigerant charge required. Verify factory charge from unit nameplate.
