Electrical Data
208/230V-60 Hz-1 Ph
Model Number Label Rev.
Unit Compressor Condenser Fan
Maximum
Over-
current
Protection
(amps)
1
Minimum
Circuity
Ampacity
2
Rated
Load
Amps
(RLA)
Locked
Rotor
Amps
(LRA)
Motor HP
Nominal
RPM
Full Load
Amps
(FLA)
Locked
Rotor
Amps
(LRA)
XP14-018-230-01
1.0, 2.0 &
3.0
20 11.9 8.97 48.0 1/10 1075 0.7 1.4
XP14-018-230-02 1.0 20 11.9 8.97 48.0 1/10 1075 0.7 1.4
XP14-018-230-03 1.0 20 11.9 8.97 48.0 1/10 1075 0.7 1.4
XP14-018-230-06 1.0 20 11.9 8.97 48.0 1/10 1075 0.7 1.4
XP14-018-230-07
1.0 20 11.9 8.97 48.0 1/10 1075 0.7 1.4
2.0 20 12.3 9.00 48.0 1/10 1075 0.7 1.4
3.0 20 12.2 9.00 48.0 1/10 1075 0.7 1.4
XP14-018-230-08
1.0 20 11.9 8.97 48.0 1/10 1075 0.7 1.87
2.0 20 12.3 8.96 48.0 1/6 825 1.1 1.87
3.0 20 12.3 8.96 48.0 1/6 825 1.1 1.87
XP14-018-230-09
1.0 20 12.3 8.96 48.0 1/6 825 1.1 1.87
2.0 20 12.3 9.00 48.0 1/6 825 1.1 1.87
3.0 20 12.2 9.00 48.0 1/6 825 1.0 1.87
208/230V-60 Hz-1 Ph
Model Number Label Rev.
Unit Compressor Condenser Fan
Maximum
Over-
current
Protection
(amps)
1
Minimum
Circuity
Ampacity
2
Rated
Load
Amps
(RLA)
Locked
Rotor
Amps
(LRA)
Motor HP
Nominal
RPM
Full Load
Amps
(FLA)
Locked
Rotor
Amps
(LRA)
XP14-024-230-01 1.0 & 2.0 30 17.5 13.46 58.0 1/10 1075 0.7 1.4
XP14-024-230-02 1.0 30 17.5 13.46 58.0 1/10 1075 0.7 1.4
XP14-024-230-03 1.0 30 17.5 13.46 58.0 1/10 1075 0.7 1.4
XP14-024-230-06 1.0 30 17.5 13.46 58.0 1/10 1075 0.7 1.4
XP14-024-230-07
1.0 30 17.5 13.46 58.0 1/10 1075 0.7 1.4
2.0 30 17.9 13.50 58.0 1/10 1075 0.7 1.4
3.0 30 17.8 13.50 58.0 1/10 1075 0.7 1.4
XP14-024-230-08
1.0 30 17.5 13.46 58.0 1/10 1075 0.7 1.4
2.0, 3.0 &
4.0
30 17.9 13.44 58.0 1/6 825 1.1 1.87
XP14-024-230-09
1.0 & 2.0 30 17.9 13.44 58.0 1/6 825 1.1 1.87
3.0 30 17.9 13.50 58.0 1/6 825 1.1 1.87
