XP14 SERIES
208/230V-60 Hz-1 Ph
Model Number Label Rev.
Unit Compressor Condenser Fan
Maximum
Over-
current
Protection
(amps)
1
Minimum
Circuity
Ampacity
2
Rated
Load
Amps
(RLA)
Locked
Rotor
Amps
(LRA)
Motor HP
Nominal
RPM
Full Load
Amps
(FLA)
Locked
Rotor
Amps
(LRA)
XP14-030-230-01
1.0, 2.0 &
3.0
30 17.0 13.1 64.0 1/10 1075 0.7 1.4
XP14-030-230-02 1.0 30 17.0 13.1 64.0 1/10 1075 0.7 1.4
XP14-030-230-03 1.0 30 17.0 13.1 64.0 1/10 1075 0.7 1.4
XP14-030-230-05
1.0 30 17.0 13.1 64.0 1/10 1075 0.7 1.4
2.0 30 19.4 14.1 64.0 1/10 1075 0.7 1.4
XP14-030-230-06 1.0 30 17.0 13.1 64.0 1/10 1075 0.7 1.4
XP14-030-230-07
1.0 30 17.0 13.1 64.0 1/10 1075 0.7 1.4
2.0 30 17.5 13.1 64.0 1/10 1075 0.7 1.4
3.0 30 17.4 13.1 64.0 1/10 1075 0.7 1.4
XP14-030-230-08
1.0 30 17.0 13.1 64.0 1/10 1075 0.7 1.4
2.0 & 3.0 25 17.1 12.8 64.0 1/6 825 1.1 1.87
XP14-030-230-09
1.0 25 17.1 12.8 64.0 1/6 825 1.1 1.87
2.0 30 17.5 13.1 64.0 1/6 825 1.1 1.87
3.0 30 17.4 13.1 64.0 1/6 825 1.1 1.87
208/230V-60 Hz-1 Ph
Model Number Label Rev.
Unit Compressor Condenser Fan
Maximum
Over-
current
Protection
(amps)
1
Minimum
Circuity
Ampacity
2
Rated
Load
Amps
(RLA)
Locked
Rotor
Amps
(LRA)
Motor HP
Nominal
RPM
Full Load
Amps
(FLA)
Locked
Rotor
Amps
(LRA)
XP14-036-230-01
1.0, 2.0 &
3.0
30 19.4 14.1 77.0 1/3 825 1.8 2.9
XP14-036-230-02 1.0 30 19.4 14.1 77.0 1/3 825 1.8 2.9
XP14-036-230-08
1.0 30 19.4 14.1 77.0 1/3 825 1.8 2.9
2.0 30 18.7 14.08 77.0 1/6 825 1.1 1.87
XP14-036-230-09 1.0 30 18.7 14.08 77.0 1/6 825 1.1 1.87
XP14-036-230-10 1.0 & 2.0 30 18.7 14.08 77.0 1/6 825 1.1 1.87
208/230V-60 Hz-1 Ph
Model Number Label Rev.
Unit Compressor Condenser Fan
Maximum
Over-
current
Protection
(amps)
1
Minimum
Circuity
Ampacity
2
Rated
Load
Amps
(RLA)
Locked
Rotor
Amps
(LRA)
Motor HP
Nominal
RPM
Full Load
Amps
(FLA)
Locked
Rotor
Amps
(LRA)
XP14-042-230-01
1.0 40 23.9 17.69 107.0 1/3 825 1.8 2.9
2.0 & 3.0 40 24.2 17.94 112.0 1/3 825 1.8 2.9
XP14-042-230-02 1.0 40 24.2 17.94 112.0 1/3 825 1.8 2.9
XP14-042-230-08
1.0 40 24.2 17.94 112.0 1/3 825 1.8 2.9
2.0, 3.0 &
4.0
40 24.2 17.92 112.0 1/3 825 1.8 2.9
XP14-042-230-09
1.0 40 24.2 17.92 112.0 1/3 825 1.8 2.9
2.0 40 24.2 18.0 112.0 1/3 825 1.8 2.9
