Page 6
208/230V-60 Hz-1 Ph
Model Number Label Rev.
Unit Compressor Condenser Fan
Maximum
Over-
current
Protection
(amps)
1
Minimum
Circuity
Ampacity
2
Rated
Load
Amps
(RLA)
Locked
Rotor
Amps
(LRA)
Motor HP
Nominal
RPM
Full Load
Amps
(FLA)
Locked
Rotor
Amps
(LRA)
XP14-048-230-01
1.0, 2.0 &
3.0
50 29.0 21.79 117.0 1/3 825 1.8 2.1
XP14-048-230-02 1.0 50 29.0 21.79 117.0 1/3 825 1.8 2.1
XP14-048-230-08 1.0 50 29.0 21.76 117.0 1/3 825 1.8 2.1
XP14-048-230-09
1.0 50 29.0 21.79 117.0 1/3 825 1.8 2.1
2.0 & 3.0 50 29.0 21.76 117.0 1/3 825 1.8 2.1
208/230V-60 Hz-1 Ph
Model Number Label Rev.
Unit Compressor Condenser Fan
Maximum
Over-
current
Protection
(amps)
1
Minimum
Circuity
Ampacity
2
Rated
Load
Amps
(RLA)
Locked
Rotor
Amps
(LRA)
Motor HP
Nominal
RPM
Full Load
Amps
(FLA)
Locked
Rotor
Amps
(LRA)
XP14-060-230-01 1.0 & 2.0 60 34.8 26.41 134.0 1/3 825 1.8 2.1
XP14-060-230-03 1.0 60 34.8 26.41 134.0 1/3 825 1.8 2.1
XP14-060-230-08
1.0 60 34.8 26.41 134.0 1/3 825 1.8 2.1
2.0, 3.0 &
4.0
50 29.4 22.10 125.0 1/3 825 1.8 2.1
XP14-060-230-09 1.0 60 29.4 26.41 125.0 1/3 825 1.8 2.1
1
HACR type circuit breaker or fuse.
2
Refer to National or Canadian Electrical Code manual to determine wire, fuse and disconnect size requirements.
