Table 5. Unit Indoor Matchups for Subcooling (XP14-XXX-230-01 through 07)
INDOOR MATCHUPS
Target
Subcooling
HeatingCooling
(+5ºF) (+1ºF)
*Add
charge
INDOOR MATCHUPS
Target
Subcooling
HeatingCooling
(+5ºF) (+1ºF)
*Add
charge
INDOOR MATCHUPS
Target
Subcooling
HeatingCooling
(+5ºF) (+1ºF)
*Add
charge
XP14−018 lb oz XP14−030 (Continued) lb oz XP14−042 (Continued) lb oz
CBX27UH-018/024 13 7 0 8 CH33-42B 6 6 1 12 CR33-50/60C,-60D 26 6 0 4
CBX32MV-018/024 15 7 0 0 CR33-30/36A/B/C 30 8 0 8 CX34-62C, -62D 12 6 0 9
CBX40UHV-024 15 7 0 0 CX34-31A/B 11 6 1 6 CX34-49C 12 6 0 7
XP14−024 lb oz
CX34-38A/B S/N# 6007
and after
6 6 2 3 CX34-60D 12 6 0 4
CBX26UH-024 25 7 0 0
CX34-38A/B Before S/N#
6007
11 6 2 3 XP14−048 lb oz
CBX27UH-018/024 15 8 1 2 CX34-43B/C 15 11 2 14 CBX26UH-048 8 7 1 9
CBX32M-018/024 16 8 0 14 XP14−036 lb oz CBX27UH-048 11 8 1 2
CBX32M-030 15 8 1 3 C33-44C 13 6 0 0 CBX32M-048, -060 11 8 1 2
CBX32MV-018/024 16 8 0 14 CBX26UH-036 26 5 0 0 CBX32MV-048 25 8 0 0
CBX32MV-024/030 15 8 1 2 CBX26UH-037 25 4 1 9 CBX32MV-060 11 8 1 2
CBX40UHV-024 16 8 0 14 CBX27UH-036 13 6 0 3 CBX40UHV-048 25 8 0 0
CBX40UHV-030 15 8 1 2 CBX32M-036 13 6 0 2 CBX40UHV-060 11 8 1 2
CH23-41 16 8 0 2 CBX32M-042 13 6 0 3 CBX32MV-068 10 7 1 12
CH33-25A 16 6 0 7 CBX32MV-036 13 6 0 3 CH23-68 20 9 2 9
CH33-42B 14 11 1 10 CBX32MV-048 11 8 2 5 CH33-50/60C 11 8 1 1
CH33-36A 16 8 1 0 CBX40UHV-036 13 6 0 3 CH33-62D 10 7 1 14
CH33-36C 16 8 0 4 CBX40UHV-042, -048 11 8 2 5 CH33-60D 11 8 0 0
CR33-30/36A/B/C 25 7 0 2 CH33-50/60C 11 8 2 5 CR33-50/60C 35 5 0 0
CX34-25A/B 16 8 0 14 CH33-44B 13 6 1 7 CR33-60D 37 6 0 0
CX34-31A/B 15 8 1 3 CH33-48B 13 6 1 8 CX34-62C, -62D 10 7 1 7
CX34-36A/B/C 16 8 1 8 CR33-50/60C 25 4 1 15 CX34-49D 11 8 0 14
CX34-38A/B S/N# 6007
and after
11 11 2 2 CR33-48B/C 25 5 0 9 CX34-60D 11 8 0 0
CX34-38A/B before S/N#
6007
14 11 2 2 CX34-49C 13 6 2 4 XP14−060 lb oz
XP14−030 lb oz CX34-43B/C, -50/60C 13 6 1 8 CBX26UH-048 12 7 1 0
CH23-41 11 6 0 8
CX34-38A/B S/N# 6007
and after
6 6 0 0 CBX26UH-060 14 4 0 0
CH23-51 6 6 1 12
CX34-38A/B before S/N#
6007
13 6 0 0 CBX27UH-060 12 5 0 0
CBX26UH-024 30 8 0 6 XP14−042 lb oz CBX32M-048, -060 12 5 0 0
CBX26UH-030 29 8 2 3 CH23-68 20 9 0 13 CBX32MV-048, -060 12 5 0 0
CBX27UH-030 11 6 2 4 CBX26UH-042 27 6 0 0 CBX40UHV-048, -060 12 5 0 0
CBX32M-030 11 6 1 6 CBX27UH-042 12 6 0 8 CBX32MV-068 12 7 1 0
CBX32M-036 11 6 2 4 CBX32M-048 12 6 0 7 CH23-68 12 5 0 0
CBX32MV-024/030 11 6 1 6 CBX32MV-048 12 6 0 8 CH33-50/60C 12 5 0 0
CBX32MV-036 15 7 3 0 CBX40UHV-042, -048 12 6 0 8 CH33-62D 12 5 0 0
CBX40UHV-024, -030 11 6 1 6 CH33-43 12 6 0 7 CX34-62C, -62D 12 7 1 0
CBX40UHV-036 15 7 3 0 CH33-62D 12 6 0 10
*Add charge = Extra matchup amount required in addi
tion to charge indicated on Heat Pump nameplate (re
member to also add any charge required for line set
differences from 15 feet). SN indicates serial number.
C33-44C 11 6 2 3 CH33-50/60C 12 6 0 7
CH33-36C 11 3 0 0 CH33-60D 12 6 0 4
