When installing:
• Ensure that the connector is attached firmly.
• Do not press the top of the fan cover and the fan hub.
• Before you attach the fan assembly to the computer, apply thermal grease, at an amount of 0.2 grams, on
the part marked
a and b as shown in the following illustrations. Either too much or too less application of
grease can cause a thermal problem due to imperfect contact with a component.
ThinkPad E590/R590
• For models with discrete thermal pipes:
• For models with an integrated thermal pipe:
ThinkPad E595
1050 Memory module
For access, remove this FRU:
• “1010 Base cover assembly” on page 60
Chapter 8. Removing or replacing a FRU 67
