When installing: Ensure that the LCD connector is attached firmly.
1170 Keyboard bezel assembly
For access, remove these FRUs in order:
• “1010 Base cover assembly” on page 60
• “1020 Built-in battery” on page 62
• “1030 M.2 solid-state drive and brackets” on page 63
• “1040 Thermal fan assembly” on page 66
• “1050 Memory module” on page 67
• “1060 Internal storage drive, cable and bracket” on page 68
• “1070 Wireless LAN card” on page 69
• “1080 Coin-cell battery” on page 70
• “1090 Keyboard” on page 70
Note: If the keyboard must be removed to access other FRUs, you need the keyboard removal tool
(product part number: 01LX856) to remove the keyboard. You can purchase the tool as a separate FRU at:
https://support.lenovo.com/partslookup
• “1100 USB card cable” on page 73
• “1110 USB card” on page 73
• “1120 Speaker assembly” on page 75
• “1130 Fingerprint reader cable, bracket and card (for E590/R590)” on page 76
• “1140 Trackpad and cable” on page 77
• “1150 System board” on page 79
• “1160 LCD unit” on page 81
2010 LCD bezel
For access, remove this FRU:
• “1160 LCD unit” on page 81
Chapter 8. Removing or replacing a FRU 83
